Model PFXSP5800WCD from Schneider Electric and Pro-face. Alternate Model Name SP-5800WC. A massive 19-inch Modular SP5000 Display with a resolution of 1,366 x 768 pixels (FWXGA).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXSP5800WCD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXSP5800WCD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
Model PFXSP5800WCD from Schneider Electric and Pro-face. Alternate Model Name SP-5800WC. A massive 19-inch Modular SP5000 Display with a resolution of 1,366 x 768 pixels (FWXGA).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXSP5800WCD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXSP5800WCD Technical Specifications

Dimensions W483 x H337 x D69mm (W19.02 x H13.27 x D2.72 in.)
Enclosure Type IP65F, IP67F
Features USB (Type A) x 1 USB (mini B) x 1
Input Voltage 24VDC
Keypad/Display Projected Capacitive (5 points multi-touch)
LCD Type TFT Type Color LCD
Manufacturer Pro-Face by Schneider Electric
Model SP-5800WC
Resolution 1,366 x 768 pixels (FWXGA)
Screen Size 19-inch wide

Product Description

Part of the SP5000 series is the display monitor PFXSP5800WCD, or SP-5800WC. It is more commonly found under model number PFXSP5800WCD. This product has a display size of 19 inches wide and is complete with an auto-scaling brightness sensor. It has 16 million display colors and a white LED backlight. This monitor is also equipped with a Projected Capacitive touch panel, which has a resolution of 2,048 x 2,048. The backlight has a service life of 50,000 hours or more, with the touch panel has a service life of 50 million times or more.

Operating specifications for display monitor PFXSP5800WCD SP-5800WC include;

  • Input voltage of 12 - 24 Vdc.
  • Voltage limits of 10.8 to 28.8 Vdc.
  • Allowable voltage drop between 1.25 ms and 5 ms.
  • Inrush current of 30 A or less.
  • Maximum power consumption of 19 watts, with a minimum of 8 watts or less.
  • Insulation resistance of 500 Vdc.

Model PFXSP5800WCD should be used in surrounding air temperatures of 32 to 131 degrees Fahrenheit. It can be stored in temperatures ranging from -4 to 140 degrees Fahrenheit. Ambient and storage humidity should be between 10% and 90% RH.

Product PFXSP5800WCD can be found through AX Control. We will buy, sell, and repair these advanced display monitors.

  • SP-5800WC
Reviews For PFXSP5800WCD
Internal Review

The SP-5800WC or PFXSP5800WCD has a White LED Backlight with a lifespan of 50,000 hours of continuous use and an analog touch screen rated for over 1 million touches. It is recommended by the Manufacturer Pro-face to not replace these yourself. So we offer many user manuals and installation guides on our website in order for you to keep your unit healthy. If any part were to fail, we offer replacement and repair services. - AX Control Tech Team
