The Pro-Face Model SP-5600TP, or PFXSP5600TPD, is a Modular 12" TFT Display to be connected to the Smart Portal SP5000 Series Box Modules. The touch panel is multi-touch resistive analog

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXSP5600TPD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXSP5600TPD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Pro-Face Model SP-5600TP, or PFXSP5600TPD, is a Modular 12" TFT Display to be connected to the Smart Portal SP5000 Series Box Modules. The touch panel is multi-touch resistive analog

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXSP5600TPD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXSP5600TPD Technical Specifications

Dimensions W315 x H241 x D67mm (W12.4 x H9.49 x D2.64 in.)
Display Color 16 Million Colors
Enclosure Type IP65F, IP67F
Features USB (Type A) x 1 USB (mini B) x 1
Input Voltage 12...24 Vdc
Keypad/Display Resistive Film (analog, 2 points multi-touch)
LCD Type TFT
Manufacturer Pro-Face
Model SP-5600TP
Resolution 1,024 x 768 pixels (XGA)
Screen Size 12.1 Inch

Product Description

Part of the Pro-face SP5000 series is the product model PFXSP5600TPD SP-5600TP. This advanced display monitor is in the HMI family and is also found under model number PFXSP5600TPD. The monitor has a display size of 12 inches and a resolution of 1,024 x 768 pixels. It is equipped with an auto-scaling brightness sensor and has 16 million display colors. Model PFXSP5600TPD SP-5600TP uses a white LED backlight, which has a service life of more than 50,000 hours. It uses a multi-touch analog panel, with a resolution of 1,024 x 1,024. The touch panel’s lifetime is 1 million times or more.

This monitor will consume a maximum of 21 watts of power and will use less than 6 watts with the backlight off. Product PFXSP5600TPD has an inrush current of 30 A or less, and a rated input voltage of 12 to 24 Vdc. The input voltage limits range from 10.8 to 28.8 Vdc.

Model PFXSP5600TPD cannot be in environments 2,000 meters above sea level and should be kept free of corrosive gases. It should always be cooled through natural air circulation and should be operated in temperatures between 32 and 140 degrees Fahrenheit. Storage temperatures can range from -4 to 140 degrees Fahrenheit.

  • SP-5600TP
Reviews For PFXSP5600TPD
Internal Review

The SP5000 Series offers powerful TFT LCD touch panels such as the PFXSP5600TPD with brilliant colors and brightness, with the addition of great durability for use in harsh work environments. With the increase in application memory over the previous HMI series, more screens and image files can be created and used. - AX Control Tech Team
