PFXPF160DA33P00N00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
Rear-Mounted 12-inch Industrial PC PFXPF160DA33P00N00 from Pro-face's PS-4600 Series. This unit features zero slots Celeron 827E CPU 3GB RAM with an AC Power supply

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXPF160DA33P00N00 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXPF160DA33P00N00

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.33 (3)
  • Click a star to rate this product
Rear-Mounted 12-inch Industrial PC PFXPF160DA33P00N00 from Pro-face's PS-4600 Series. This unit features zero slots Celeron 827E CPU 3GB RAM with an AC Power supply

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXPF160DA33P00N00 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXPF160DA33P00N00 Technical Specifications

CPU CeleronĀ® M 827E 1.40 GHz
Dimensions W292 x H246 x D69 mm [W11.50 x H9.69 x D2.71 in.]
Enclosure Type Rear Mount
Input Voltage AC100V
Manufacturer Pro-Face
Model PS-4600
Resolution 1024 x 768 pixels (XGA)
Screen Size 12 Inch
Series PS-4600
Slot Type 0 Slot
Software Version Windows XP Pro MUI
Weight 3.9 kg [8.59 lb]

Product Description

The PFXPF160DA33P00N00 is a PS4600 12-inch rear-mount Industrial PC.  This is part of Pro-face Xycom’s PS4000 series.

The PFXPF160DA33P00N00 includes a Celeron 827E CPU.  This is a single-core CPU, 1.40 GHz with a 1.5 MB Intel Smart Cache.  The CPU can support up to two displays.  It includes enhanced Intel SpeedStep tech as well as thermal monitoring.  This Industrial PC uses a passive heat sink as well as a fan kit to maintain optimal working temperature.    The system includes Intel HD graphics 3000 with up to 1 GB of video memory pulled from the main memory.  DVI resolution is up to 1920 x 1200.

The PFXPF160DA33P00N00 uses an AC power supply.  This has a rated voltage of 100 to 240 VAC with a frequency of 50/60 Hz.   Inrush current with a cold restart is <20 Amps.  This unit is built with the Windows XP Pro MUI operating system.    It has an additional 500 GB of storage through a built-in HDD storage device.  It includes two serial interfaces, USB ports, as well as two 10/100/1000 Ethernet LAN ports.

When installed according to OEM specifications, the unit provides a protective value equivalent to IP65 or NEMA 4X.   The operating temperature can vary.  Please see the associated manuals for details.

The PFXPF160DA33P00N00 supports multiple languages out of the box, including Arabic, Chinese, Finnish, French, Greek, Japanese, Portuguese, Russian, and Turkish.

The PFXPF160DA33P00N00 weighs approximately 4.0 kg before preparation for shipping.  If you have questions about turnaround time or availability, please reach out to our team.


Reviews For PFXPF160DA33P00N00
Internal Review

This is a rear-mount industrial PC from Pro-face's PS4000 series. Rear mount models can only be installed in panels with a thickness of 2.3 mm (0.09 inches). Make sure when you install that the gasket is properly attached to the industrial PC. This gasket is key to a proper installation. --AX Control Tech Team.

Repair Services For PFXPF160DA33P00N00

Type Lead Time Price Action
Repair Service 1-2 weeks $581

Our highly skilled technicians can repair your PFXPF160DA33P00N00. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
