Model PL7930-T42 from Digital Electronics is a touch panel HMI with a color XGA TFT 15 inch LCD display with 1024 x 768 resolution and an Intel Pentium M (1.6GHz), or Intel Celeron M (1.3 GHz).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PL7930-T42 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PL7930-T42

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (1)
  • Click a star to rate this product
Model PL7930-T42 from Digital Electronics is a touch panel HMI with a color XGA TFT 15 inch LCD display with 1024 x 768 resolution and an Intel Pentium M (1.6GHz), or Intel Celeron M (1.3 GHz).

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PL7930-T42 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PL7930-T42 Technical Specifications

Display Type TFT Type Color LCD
Features Model Attached Fan
Model Number 3480901-06
Screen Size 15 inches
Slot Type 4 Slot Type

Product Description

The PL7930-T42 is an industrial computer that was originally designed and marketed by Pro-Face to be used in industrial applications. This computer is built to withstand the challenges of industrial settings while maintaining reliability and offering long life.

This unit is designed with a 15-inch TFT LCD color touch panel display capable of up to 260,000 colors, and includes four expansion slots. The unit is UL/c-UL approved and is also CE marked. The PL7930-T42 is built upon a Celeron M 1.3GHz Pentium CPU with 512KB of L2 Cache memory built-in.

The unit also includes up to 64MB of video memory. It has four serial com ports (RS-232C) along with two Ethernet ports, three RAS ports (D-sub 25 Pin male, 5 Data In, 4 Data Out, +12V or +5V OUT) along with three USB ports, two LAN ports, and I/O connectors for sound and mic inputs. The unit has one ISA slot and two PCI/ISA slots. An internal clock is rated with an accuracy of +/-180 seconds per month.

The unit is cooled by an internal fan, but should only be used within surrounding air temperatures of 5 to 50 degrees Celsius. The display on the PL7930-T42 includes a replaceable CCFL with a service life of 50,000 hours. The display has a viewing angle of 120 degrees horizontally and 100 degrees vertically and offers four levels of brightness control that is controlled via software.

 Please review all warnings and notes located within OEM manuals and user guides regarding the installation of this product before starting any type of maintenance. This is to protect both workers and machinery.

Reviews For PL7930-T42
Internal Review

The PL7930-T42 by Pro-Face was designed around a Celeron M 1.3 GHz and contains 4-slots that allow for PCI/ISA expansion boards. Paired with a bigger 15 inch display, it is a fantastic choice for any factory floor. - AX Techs

Repair Services For PL7930-T42

Type Lead Time Price Action
Repair Service 1-2 weeks $405

Our highly skilled technicians can repair your PL7930-T42. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
