AGP3301-L1-D24

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Pro-Face Xycom AGP3301-L1-D24 is a touch panel HMI that features a 5.7 inch QVGA monochrome LCD with a resolution of 320 x 240 with a standard board type and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3301-L1-D24 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3301-L1-D24

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (2)
  • Click a star to rate this product
The Pro-Face Xycom AGP3301-L1-D24 is a touch panel HMI that features a 5.7 inch QVGA monochrome LCD with a resolution of 320 x 240 with a standard board type and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3301-L1-D24 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3301-L1-D24 Technical Specifications

LCD Type Monochrome LCD
Model AGP-3301L
Model Number 3280007-13
Product Type Low-cost machine
Resolution 320 x 240
Screen Size 5.7 in.

Product Description

The AGP3301-L1-D24 is a Pro-face HMI industrial operator interface designed for use in rugged settings that require a machine with more reliability.  This unit is UL listed, c/UL listed, and CE marked.  It is suitable for use in non-hazardous and Cl 1 Div 2 Groups A, B, C, and D Hazardous locations.

The AGP3301-L1-D24 has a 5.7-inch monochrome LCD touch panel with 320 x 240 p.c.i QVGA resolution.   This unit requires a 24 VDC power input and is rated for non-conductive levels of dust and limited levels of pollution (pollution degree 2.)  The unit is designed for embedded panel mounting with natural air circulation.  Do not operate outside of temperatures between zero to 50 degrees Celsius.

The AGP3301-L1-D24 has a monochrome touch screen (LCD) that offers sixteen varying shades of black and white.   It is backlit by a CCFL with a 58K hour service life.   The LCD screen can be adjusted at the panel to eight different levels of contrast and brightness.  The user should be aware that LCD screens sometimes flicker or show unevenness are certain levels of brightness and contrast.  This characteristic of LCDs does not imply a defect of the product.  Also, since LCDs are heat sensitive, the screen may seem whitish at high temperatures and blackish at low ones.

More detailed information about this unit can be accessed through ProFace manuals and user guides.  For additional information about AX Control, our warranty or trade service, or more information about payment or shipping options, please follow the links on this page.  Our team can also help you with specific questions.

Reviews For AGP3301-L1-D24
Internal Review

This HMI unit from ProFace has a single standard USB port. This is a USB 1.1 Type A. This port is most typically used for transferring projects to the HMI screen. They can also be used to attach USB hubs, barcode readers, or printers. --AX Control Tech Team.

Repair Services For AGP3301-L1-D24

Type Lead Time Price Action
Repair Service 1-2 weeks $555

Our highly skilled technicians can repair your AGP3301-L1-D24. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More

AGP3301-L1-D24 Manuals, White Papers, Data Sheets, and Troubleshooting
