The Pro-Face Xycom AGP3300-S1-D24-D81K is a touch panel HMI that features a 5.7-inch QVGA STN color LCD with a resolution of 320 x 240 with DIO board type (sink type) and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-S1-D24-D81K to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-S1-D24-D81K

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The Pro-Face Xycom AGP3300-S1-D24-D81K is a touch panel HMI that features a 5.7-inch QVGA STN color LCD with a resolution of 320 x 240 with DIO board type (sink type) and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-S1-D24-D81K to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-S1-D24-D81K Technical Specifications

LCD Type STN color LCD
Model AGP-3300S-D81
Model Number 3280007-02
Output Type DIO board type (sink type)
Resolution 320 x 240
Screen Size 5.7 in.

Product Description

The AGP3300-S1-D24-D81K  is an HMI integrated controller from ProFace.  This unit is part of the GP-3000 series of controllers designed with built-in discrete I/O.  The AGP3300-S1-D24-D81K is an all-in-one HMI/PLC solution that can support two protocol drivers at the same time.

The AGP3300-S1-D24-D81K is built with a 5.7” integrated touch screen.  This no-grid analog panel allows for improved part placement and gives the user better visibility.  This is a Hi-res STN color display that is capable of up to 4,096 colors.  The unit has a fast screen refresh due to its internal 133Mhz central processing unit.

The AGP3300-S1-D24-D81K is built with two serial interface COM ports, a USB 1.1. Type A interface that can be used for download, connecting a printer, a bar code reader, or another device, a CF Card, 10/100 Base-T Ethernet LAN connection, and six discrete inputs and 2 discrete outputs located on a sink type board.  If you need a source configuration instead of a sink configuration, look at a D81C board

The AGP3300-S1-D24-D81K is typically used with GP-Pro EX HMI development software that allows users to develop tools, expand diagnostic features, and extend simulation capabilities of their unit.

When installing the AGP3300-S1-D24-D81K, input and output signal lines should be isolated from power wiring and cables to minimize excessive noise that may cause malfunctions.   Follow installation guidelines to be sure all connections are made properly to ensure there are no loose connections that may impact input or output signals.  This information can be found through documentation like manuals and data sheets from ProFace.


Reviews For AGP3300-S1-D24-D81K
Internal Review

This Pro-face integrated control HMI connects the user with power scripting tools. It can monitor and collect device data as needed, separating it into one screen or multiple screens depending on how the user requires it. You can import your existing logic programs via software. --AX Control Tech Team.

Repair Services For AGP3300-S1-D24-D81K

Type Lead Time Price Action
Repair Service 1-2 weeks $447

Our highly skilled technicians can repair your AGP3300-S1-D24-D81K. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
