Schneider Electric's AGP3300-L1-D24-M 3.8-inch TFT HMI display with a resolution of 320 x 240. A 24DC type power supply is used. The 'M Class' of HMIs are designed with optimal video input options to allow for even recorders and other video functions.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-L1-D24-M to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-L1-D24-M

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
Schneider Electric's AGP3300-L1-D24-M 3.8-inch TFT HMI display with a resolution of 320 x 240. A 24DC type power supply is used. The 'M Class' of HMIs are designed with optimal video input options to allow for even recorders and other video functions.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-L1-D24-M to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-L1-D24-M Technical Specifications

LCD Type Monochrome LCD
Model AGP3300-L1-D24-M
Model Number 3280007-03
Resolution 320 x 240
Screen Size 5.7 in.

Product Description

The AGP3300-L1-D24-M HMI unit is one of several Pro-Face operator interfaces available on our site.  This unit is from the GP3000 series and can support up to two protocol drivers at one time.   The front display includes a status LED that allows users to quickly identify any issues with the unit.   This model requires a 24 VDC power supply.

The AGP3300-L1-D24-M is fronted by a monochrome touch panel LCD with 16 shades of black and white available.   The unit has a resolution level of 320 by 240 pixels and is backlit by a CCFL.  There are 8 levels of brightness/contrast adjustable from the touch panel.  Please be aware the LCD may flicker or show some unevenness at certain levels.  This is a characteristic of LCDs and does not imply a defect in the product.  Additionally, LCDs are heat sensitive and may seem whitish at high temperatures and blackish at low temperatures.

The AGP3300-L1-D24-M is CE marked and UL and c/UL listed.  It also meets ANSI/ISA 12.12.01 standards when it is mounted to proper standards.  Please note that liquids, water, or fragments of metal should not be allowed to enter the AGP3300-L1-D24-M case.  Any of these contaminants may cause the unit to malfunction or could cause an electric shock to occur.  Additionally, the AGP3300-L1-D24-M should not be placed in direct sunlight or other areas of high temperature, or in locations where excessive vibration, dust, or moisture is a concern.

For additional information and specifications for the AGP3300-L1-D24-M, please refer to Pro-face documents like manuals and data sheets that refer to this unit.  More information about shipping and payment options is available from the links on this page.


Reviews For AGP3300-L1-D24-M
Internal Review

This multi-port HMI from the Proface GP3000 series offers vibration and shock resistance when properly installed. Proper installation also conveys NEMA 4x/13 or IP65f ratings. Up to sixteen devices can connect to the RS-422 port. --AX Control Tech Team.
