Proface AGP3300-L1-D24-D81K is a touch panel HMI that feature a 5.7 inch QVGA black and white monochrome LCD with a resolution of 320 x 240 dots and a CANopen board type and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-L1-D24-D81K to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-L1-D24-D81K

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Proface AGP3300-L1-D24-D81K is a touch panel HMI that feature a 5.7 inch QVGA black and white monochrome LCD with a resolution of 320 x 240 dots and a CANopen board type and DC type power supply is used.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a AGP3300-L1-D24-D81K to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

AGP3300-L1-D24-D81K Technical Specifications

LCD Type Monochrome LCD
Model Number 3280007-03
Output Type DIO board type (sink type)
Power Type DC Type Power Supply
Resolution 320 x 240
Screen Size 5.7 in.

Product Description

The AGP3300-L1-D24-D81K is a 5.7” integrated HMI controller from the DS3000 series of Pro-face operator interfaces.  This unit can also be identified by the global code PFXGP3300LADDK.

The AGP3300-L1-D24-D81K is an all-inclusive HMI/PLC controller that includes six discrete inputs along with 2 discrete outputs.   The monochrome display offers a 320 x 240 d.p.i resolution on its no-grid touchscreen.  The unit is built with an internal 64-bit RISC 133Mhz central processing unit.  This allows for fast data sampling and screen refresh times.  Up to sixteen devices can be connected to the AGP3300-L1-D24-D81K through its RS-422 port.

The AGP3300-L1-D24-D81K  uses GP-Pro Ex HMI development software.  This program uses a simple drag and drop operations and also has re-usable sub-routines that will reduce the number of steps needed to develop product programs.  The unit also offers a feature that allows for online logic program monitoring directly on the HMI without the need for a connected laptop.  This helps to quickly identify and correct sequential logic faults.

The AGP3300-L1-D24-D81K uses a 24V DC input voltage.  Its rated voltage is 19.2V DC to 28.8V DC and the unit has a power consumption of 26W or less.   This unit should be used in ambient conditions between 32 and 122 degrees Fahrenheit.  The unit is designed for use in areas where the temperature does not have large sudden temperature changes.  Such changes can lead to condensation within the machine that could cause machine malfunction.

Additional specifications for the AGP3300-L1-D24-D81K may be found by reading through original publications from Pro-face like manuals and user guides.  Please review all-important handling instructions before installation.


Reviews For AGP3300-L1-D24-D81K
Internal Review

This Pro-face Operator Interface is an all-in-one HMI/PLC that is designed with built-in discrete I/O. The unit can support two protocol drivers at the same time, and is capable of displaying high-def part images on its no-grid analog touch panel display. --AX Control Tech Team.
