PFXGP4501TADW

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.31 (13)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.31 (13)
  • Click a star to rate this product
The PFXGP4501TADW Proface 10.4-inch Human Machine Interface
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a PFXGP4501TADW to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXGP4501TADW
  • SKU: PX-17983
  • Manufacturer: Pro-face by Schneider Electric
  • Series: GP4000 Series

PFXGP4501TADW Technical Specifications

Manufacturer Pro-Face
Part Number PFXGP4501TADW
Display Color 65,536 Colors
Display Type TFT Color LCD
Input Voltage DC24V
Resolution 640 x 480 dots (VGA)
Screen Size 10.4-inch
Shipping Weight 4.44 lb
Software Version GP-Pro EX

About the PFXGP4501TADW

  • Rated Input Voltage: 24 VDC
  • Input Voltage Limit: 19.2-28.8 VDC
  • Allowable Voltage Drop: 10 ms or less
  • Power Consumption: 17 watts or less
  • In-rush Current: 30 A or less
  • Cleaning: Clean the display panel (do not use paint thinner)
  • Backlight: Occasionally change the backlight
PFXGP4501TADW Display and Touch Panel Details
  • Display Type: 10.4 inch TFT Color LCD display
  • Resolution (VGA): 640 x 480 pixels
  • Effective Display Area: 8.31 in x 6.34 in
  • Touch Panel Type: Analog resistive film
  • Touch Panel Resolution: 1,024 x 1,024
  • Touch Panel Service Life: 1,000,000 times or more
PFXGP4501TADW Connectivity
  • SD Card Slot: One slot
  • Serial Communication Ports: Two Ports
  • USB Ports: Two USB Ports
  • Ethernet Port (LAN): One Port
PFXGP4501TADW Device Environmental Requirements and Dimensions
  • Allowable Dust: 0.1 mg/m³ (10⁻⁷ oz/ft³) or less at non-conductive levels
  • Pollution Degree: No greater than a Degree 2 environment
  • Atmosphere: Must be free of corrosive gases
  • Air Pressure: Must remain between 800 and 1,114 hPA
  • Altitude: Must stay under 2,000 meters (6,561 feet) above sea
  • External Dimensions (W x H x D): 272.5 x 214.5 x 57 mm [10.73 x 8.44 x 2.24 in]
  • Panel Thickness Area: 1.6 to 5 mm [0.06 to 0.2 in]

Frequently Asked Questions about PFXGP4501TADW

Does this PFXGP4501TADW HMI's chassis feature any venting?

Yes. This PFXGP4501TADW Human Machine Interface's back chassis is vented for air circulation purposes as pictured.

Is the PFXGP4501TADW a revised HMI product from ProFace/GP4000?

Yes. This is a revised GP4000 Series product, being based off of the original PFXGP4501TAD offering also available for repair or replacement now.

Reviews For PFXGP4501TADW

Internal Review
(4.0)

The PFXGP4501TADW HMI from Pro Face Xycom is part of the GP 4000 series. This model number shares a Datasheet with ProFace part number GP-4501TW; we have both listed on our site. The 10.4 inch VGA TFT color LCD touch panel offers a 50k lifespan backlight with eight levels of brightness control. Fonts can be expanded (width and height) up to eight times. The unique backlight service length attributed to this PFXGP4501TADW device is in the range of 50,000 hours of full use. Repair or replace with confidence from AX today. - AX Control Lead Technician

Repair Services For PFXGP4501TADW

Type Lead Time Price Action
Repair Service 1-2 weeks $648

Our highly skilled technicians can repair your PFXGP4501TADW. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
