Pro-face PFXGP4501TAA Touch Screen Operator Interface 10.4 TFT Analog Color LCD Display. 100-240 VAC.
test

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a PFXGP4501TAA to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXGP4501TAA
  • SKU: PFXGP4501TAAPX
  • Manufacturer: Pro-face by Schneider Electric
  • Series: GP4000 Series

PFXGP4501TAA Technical Specifications

Battery Lithium Battery Installed by OEM. Program Backup
Common Failures, Faults, Errors, Diagnostics 1. Defective Display 2. Bad Backlight 3. Defective Video Card
Display Type TFT Type Color LCD
Features RS-232C and RS-422/RS-485
Input Voltage AC type power supply
Manufacturer Pro-Face
Part Number PFXGP4501TAA
Resolution 640 x 480
Screen Size 10.4 inch
Software Version GP-Pro EX

About the PFXGP4501TAA

PFXGP4501TAA is a Proface Display Interface Panel with a rated input voltage of 100-240 VAC. The atmosphere for this panel must be free of corrosive gases. The pollution cannot exceed Degree 2. The dust cannot exceed 0.1 mg/m3. The concussion resistance must be IEC/EN61131-2 compliant. The vibration resistance must also be IEC/EN61131-2 compliant. The air pressure maximum is 800 to 1,114 hPA, or 2000 m above sea level. The ambient humidity may not exceed 90%. The storage temperature may not exceed 60°C. The operating temperature may not exceed 55°C. The cooling method for this panel is natural air circulation. The external dimensions are 272.5 mm (width) x 214.5 mm (height) x 57 mm (depth).

The functional grounding has a grounding resistance of 100Ω, 2mm² (AWG 14) or thicker wire, or your country's applicable standard. The contact discharge method is 6 kV and compliant with IEC/EN61000-4-2 Level 3. The allowable voltage drop is 1 cycle or less, wherein the voltage drop interval is greater than or equal to 1 second. The in-rush current is 30 A or less. At 100 VAC, the power consumption is less than or equal to 44 VA. At 240 VAC, the power consumption is less than or equal to 58 VA. The voltage endurance is 1,500 VAC and 20 mA for 1 minute between charging and the FG terminals. The insulation resistance is greater than or equal to 500 VDC, 10 MΩ. The input voltage limits are 85 VAC to 264 VAC. This panel weighs less than or equal to 2 kg.

Reviews For PFXGP4501TAA

Internal Review
(5.0)

This 10.4 inch HMI operator interface from ProFace Xycom (now Schneider Electric) offers an energy-efficient LED display with sixteen levels of brightness adjustment available. Adjustments can be made through the panel or through software. The unit includes an SD card slot with 32 GB, Serial ports, an Ethernet port, and USB ports. --AX Control Tech Team.

Repair Services For PFXGP4501TAA

Type Lead Time Price Action
Repair Service 1-2 weeks $684

Our highly skilled technicians can repair your PFXGP4501TAA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
