The Pro-face PFXGP4301TADW 5.7' Touch Panel HMI

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a PFXGP4301TADW to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXGP4301TADW
  • SKU: PX-53985
  • Manufacturer: Pro-face by Schneider Electric
  • Series: GP4000 Series

PFXGP4301TADW Technical Specifications

Software Version GP-Pro EX
Series GP4000 Series
Part/Model Number PFXGP4301TADW
Manufacturer Pro-face
Input Voltage 24VDC
Global Code GP-4301TW
Features RS-232C and RS-422/RS-485
Display Type TFT Type Color LCD
Display Color Over 60,000 Colors
Country of Origin Designed in Japan, Made in Indonesia (or China)

About the PFXGP4301TADW

The PFXGP4301TADW is a GP-4000 series human-machine interface (HMI) from Pro-face. The PFXGP4301TADW is also denoted as GP-4031TW in certain Pro-face documentation. The PFXGP4301TADW is a 5.7 inch TFT Color LCD display with a screen resolution of 320 x 240 pixels (QVGA.).The effective display area of this unit is 4.54 inches wide and 3.40 inches high. The associated analog resistive touch panel has a resolution of 1024 x 1024 with a lifetime touch service life of one million or more. The unit is backlit by a white LED and offers:

  • eight levels of brightness control adjustable through software
  • a palette of up to 65,536 colors
  • multiple language fonts including English, Korean, Chinese, and Japanese
  • 8 MB of application memory
  • 132 KB of additional logic program area
  • 128 KB of SRAM
  • a rechargeable lithium battery for backup memory

Device Inputs and Interfacing

The PFXGP4301TADW has a rated input voltage of 24 VDC with an in-rush current of 30 A or less. The unit is designed for use in areas free from corrosive gases where the air temperature remains between 0 to 50 degrees Celsius in ambient humidity of 10 to 90%, non-condensing. Additional details about the PFXGP4301TADW HMI can be found through Pro-face data sheets, user guides, and manuals. Interfaces on this unit include:

  • two serial COM ports
  • an Ethernet port
  • two USB ports
  • no SD card slot

Frequently Asked Questions about PFXGP4301TADW

Is blink function supported by this PFXGP4301TADW?

No. This specific PFXGP4301TADW HMI/Human Machine Interface has no blink capabilities.

How many levels of brightness control does the PFXGP4301TADW bring to the table?

This customizable PFXGP4301TADW HMI has eight total levels of brightness control available.

Reviews For PFXGP4301TADW

Internal Review
(5.0)

The PFXGP4301TADW should only be used in locations free from corrosive gases. This unit does not have an SD card slot but does include two serial COM ports, 2 USB ports, and an Ethernet port. DC 24 V input voltage with a 5 ms allowable voltage drop. Use ProFace manuals and user guides to help you with the finer points of maintenance and installation. A once-revised ProFace offering based on the PFXGP4301TAD. - AX Control Lead Technician
