The PFXGP4301TAD is a GP-4300 Series HMI with a 5.7 inch TFT Color LCD Display and 320 x 240 QVGA Resolution. It allows the user's program to be stored even when the HMI is powered down by coming with an internal lithium battery for battery backup.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4301TAD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4301TAD

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.67 (6)
  • Click a star to rate this product
The PFXGP4301TAD is a GP-4300 Series HMI with a 5.7 inch TFT Color LCD Display and 320 x 240 QVGA Resolution. It allows the user's program to be stored even when the HMI is powered down by coming with an internal lithium battery for battery backup.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4301TAD to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4301TAD Technical Specifications

Battery External Onboard Lithium Battery (Stores program when the HMI is powered down)
Dimensions External Dimensions: 6.12\" x 5.39\" x 2.34\"
Display Color 65,536 Colors (No blink)/16,384 Colors (Blink)
Display Type TFT Color LCD
Features RS-232C and RS-422/RS-485
Input Voltage 24VDC
Manufacturer Pro-Face or Proface
Memory Application Memory, Backup Memory, Clock Accuracy
Rated Input Voltage 24VDC Input
Resolution 320 x 240 Dots (QVGA)
Screen Size 5.7-Inch
SD Card Qty 1 SD Card Slot
Software Version GP-Pro EX
Weight 1lbs 12oz

Product Description

The PFXGP4301TAD from Proface Xycom is a 5.7 inch Human Machine Interface with a rugged touch panel designed for industrial use.  This TFT Color LCD unit is also sold under part number GP-4301T, and may sometimes land in our inventory under that ID.  Our team will be happy to provide you with an individual request for a quote that will include current stock levels and estimated shipping time for this model.  Reach out to us for more information.

The PFXGP4301TAD has a QVGA operator interface with a 320 x 240-pixel resolution.  The unit is built with a White LED backlighting the display.  While this LED is not user-replaceable, it is rated for over 50,000 hours of continuous operation before it decreases to a 50% brightness level.

The PFXGP4301TAD is designed to panel mount.  Make sure the mounting location is solid and free of warping.   This will ensure dust and other impurities won’t infiltrate behind the panel.

The PFXGP4301TAD weighs approximately 1.8 pounds for the display unit only.   It requires panel cut dimensions of 6.14 inches by 4.86 inches in a panel from 0.06 to 0.2 inches wide.  The unit does not have a fan and uses natural air circulation for cooling. It must be properly mounted to maintain its equivalent NEMA 4x rating.  Use a 2mm2  AWG 14 or thicker wiring to ensure grounding resistance of 100 ohms.  Refer to associated manuals and user guides for more information about the product and proper installation techniques.

Reviews For PFXGP4301TAD
Internal Review

The PFXGP4301TAD HMI is a Proface model designed for panel mounting. Be sure to check the panel for any signs of warping before beginning your installation, as warping may affect your installation. A warped panel should be reinforced before installation begins. Check the gasket on the rear bezel of the HMI to ensure it is properly placed during the installation as this affects how well the unit maintains its equivalent NEMA rating. --AX Control Tech Team.

Repair Services For PFXGP4301TAD

Type Lead Time Price Action
Repair Service 1-2 weeks $621

Our highly skilled technicians can repair your PFXGP4301TAD. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
