The PFXGP4105G1D is a unit from Pro-face Xycom that has a 3.4-inch Monochrome Green/Orange/Red display with a resolution of 200 x 80 and an RS-232 Port Type

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4105G1D to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4105G1D

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
The PFXGP4105G1D is a unit from Pro-face Xycom that has a 3.4-inch Monochrome Green/Orange/Red display with a resolution of 200 x 80 and an RS-232 Port Type

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a PFXGP4105G1D to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

PFXGP4105G1D Technical Specifications

Display Color 65,000 Colors
Display Type TFT Type Color LCD
Features RS-232C Type
Input Voltage DC24V
Manufacturer Pro-Face
Model Number 3910017-01
Resolution 200 x 80 Dots
Screen Size 3.4-Inch
Software Version GP-Pro EX
Weight Less than 2 lbs.

Product Description

The PFXGP4105G1D is a GP-4100 series monochrome human-machine interface.  Our site may list these units by their part number(GP-4105G) or their model number(PFXGP4105G1D).  If you can’t find what you’re looking for under either one of these numbers, please contact our team for assistance.

The PFXGP4105G1D Human-machine interface is an STN monochrome touch panel with sixteen levels of green/red/orange display coloring.   The unit is backlit by a green/red LED.  This LED is not user-replaceable but has a long 50,000 hour lifetime (green) or 10k hour lifetime (red) before the brightness decreases to 50% of its original.    The unit supports multiple fonts and users can choose to expand the original character sizes by up to eight times.

The PFXGP4105G1D unit includes 2.2 MB of Flash EPROM available application memory with 128kb of data backup.   The touch panel is an analog resistive film that has a service life of 1 million touch times or more.

At the rear of the PFXGP4105G1D, the user will find several connection port options.  This includes a Serial COM port for asynchronous transmission of data at speeds up to 115.2 kbps.   The unit also has a USB type mini-b and a USB type A  that can be used for data transmission, for connecting a USB stick, or for connecting other USB devices including bar code readers.    Bar code readers must have power supplied by an external power source.

Additional details about the PFXGP4105G1D unit, including specifics regarding its installation, can be sourced from Proface manuals and data sheets.


Reviews For PFXGP4105G1D
Internal Review

The PFXGP4105G1D HMI from Proface Xycom supports multiple font options on its display. This includes different language fonts, different heights, and different widths. This unit can support English, Japanese, Korean, Thai, ASCII, Cyrillic script, and Chinese. Fonts can expand up to eight times in width and height, with associated limitations on characters and rows--AX Control Tech Team.

Repair Services For PFXGP4105G1D

Type Lead Time Price Action
Repair Service 1-2 weeks $684

Our highly skilled technicians can repair your PFXGP4105G1D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
