The PFXGM4301TAD Touchscreen Display HMI

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a PFXGM4301TAD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXGM4301TAD
  • SKU: PX-17637
  • Manufacturer: Pro-face by Schneider Electric
  • Series: GP4000 Series

PFXGM4301TAD Technical Specifications

Display Color 65,536 Colors
Display Type TFT Type Color LCD
Features Modular
Input Voltage 24VDC
Manufacturer Pro-Face
Resolution 320 x 240 Dots (QVGA)
Screen Size 5.7-Inch
Software Version GP-Pro EX

About the PFXGM4301TAD

PFXGM4301TAD is a control panel interface that is manufactured by Proface, now a subsidiary of Schneider Electric.

When setting up the control panel:

  • Ensure that the unit will be mounted in clean, dry enclosure
  • The surface on which the panel is installed must be flat with no jagged edges
  • The user may implement metal reinforcing strips to make the panel more rigid
  • Design the panel installation to minimize vibration resonance
  • Ensure that the heat from the surrounding equipment does not cause the panel to exceed its specified operating temperature
  • The panel face cannot be inclined more than 30 degrees in either direction
  • The right side of the unit must face up when mounted vertically, and the unit must be at least 100 mm away from other equipment

The control panel interface has a white LED backlight that will last for 50,000 hours or more at 25° C. The standard font sizes on the display are 8 x 8, 8 x 16, 16 x 16, and 32 x 32. The Ethernet interface is IEEE802.3i/ IEEE802.3u, 10BASE-T/100BASE-TX, and the connector is a modular jack. This unit uses an external clock to accurately tell the time. The functional grounding should have a grounding resistance of 100Ω, and the grounding wire should be 2mm² (AWG 14) or thicker. The weight of this unit is 0.62 kg or less. The atmosphere where this unit is mounted must be free of corrosive gas. The unit must be cooled down with natural air circulation. The vibration resistance is IEC/EN61131-2 compliant, 5 to 9 Hz Single amplitude 3.5 mm.


Frequently Asked Questions about PFXGM4301TAD

How many brightness levels does the PFXGM4301TAD have?

This unit has 16 levels of brightness.

What is the power consumption maximum of the PFXGM4301TAD?

The PFXGM4301TAD has a max power consumption level of 6.8 watts.

Reviews For PFXGM4301TAD

Internal Review
(5.0)

If you are looking for a GP4000 series HMI that uses a 22mm mount rather than a traditional panel cutout, this unit is designed for that. The PFXGM4301TAD is built with separate front and rear modules that connect through a 22mm mounting hole, holding the unit in place. 5.7-inch unit. 24VDC. UL listed, RoHS compliant. --AX Control Tech Team.
