Pro-face Xycom's GP4106G1D (part of the GP4000 Series) 3.4-inch Green, Orange, and Red Monochrome HMI with S-422/485 type port and DC24V

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP4106G1D to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP4106G1D

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (2)
  • Click a star to rate this product
Pro-face Xycom's GP4106G1D (part of the GP4000 Series) 3.4-inch Green, Orange, and Red Monochrome HMI with S-422/485 type port and DC24V

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP4106G1D to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP4106G1D Technical Specifications

Display Color Monochrome Green/Orange/Red
Display Type STN Monochrome
Features RS-422/485
Global Code PFXGP4106G1D
Input Voltage 24VDC
Manufacturer Pro-Face
Model Number 3910017-03
Resolution 200 x 80 Dots
Screen Size 3.4-Inch
Software Version GP-Pro EX
Weight Less than 2 lbs.

Product Description

The GP4106G1D is one of several GP4100 monochrome operator interfaces (HMIs) in our everyday inventory.   Proface made different color variations of this 3.4-inch workhorse human-machine interface to meet the needs of different users and locations.

The GP4106G1D Proface HMI is a 3.4-inch monochrome operator interface.  This unit has a resolution of 200 x 80 and is a green/orange/red unit.  GP4100 Proface HMIs come in a number of different color options, so if this one is not exactly what you’re looking for we have other options available in our inventory.   The GP4106G1D uses a DC 24 V supply for power and has an allowable voltage drop rated at 3 ms or less.   The unit has a power consumption of 3.0 W or less when not supplying power to USB devices, or 6.2 W or less when USB devices are being powered by the HMI.

The GP4106G1D is designed for use in 10-90% relative humidity non-condensing where the temperature remains between zero to 50 degrees Celsius.  It is important to understand that at the upper range of the HMI’s working temperature range the display may show some fading; this is a normal reaction to long exposure to high temperatures.   The unit is IEC/EN61131-2 compliant for vibration and concussion resistance.  For additional information as well as for important details regarding this unit’s installation, please refer to the original ProFace manuals and user guides.

Reach out to AX Control’s team for an up-to-date inventory count at any time.  We will be happy to provide you with cost and turnaround information for your specific location.


Reviews For GP4106G1D
Internal Review

The GP4100 HMI will give you long and reliable service. Follow all information listed in its associated manual. Don't operate the HMI in locations where chemicals are present or use the HMI in direct sunlight, as this may deteriorate the LCD's quality--AX Control Tech Team.

Repair Services For GP4106G1D

Type Lead Time Price Action
Repair Service 1-2 weeks $647

Our highly skilled technicians can repair your GP4106G1D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
