What is the memory application of the GP4105W1D?

The GP4105W1D has 2.2 MB of Flash EPROM memory.

What is the pollution degree of this unit?

The GP4105W1D can be installed in a pollution Degree 2 environment.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home Pro-face Xycom GP4000 Series GP4105W1D

❮

❯

About | Product Specifications | FAQs

GP4105W1D

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The GP4105W1D Human-Machine Interface

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a GP4105W1D to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: GP4105W1D
SKU: PX-54255

Manufacturer: Pro-face by Schneider Electric
Series: GP4000 Series

Description
Repairs
Warranty
Manuals

GP4105W1D Technical Specifications

Display Color	Monochrome White/Pink/Red
Display Type	STN Monochrome
Features	RS-232C Type
Global Code	PFXGP4105W1D
Input Voltage	DC24V
Manufacturer	Pro-Face
Model Number	3910017-02
Resolution	200 x 80 Dots
Screen Size	3.4-Inch
Software Version	GP-Pro EX

About the GP4105W1D

The ProFace GP4105W1D is a monochrome human-machine interface (HMI) operator interface. Proface Xycom (now owned by Schneider Electric) built and sold a number of different monochrome operator interfaces with different limited palettes. These units may also vary in the type of interface connections they offer. The GP4105W1D is a monochrome STN HMI measuring 3.4 inches. It has:

a resolution of 200 x 80
a White/Pink/Red monochrome option
a variety of different color options
a DC 24 V power supply
a Serial COM port that is an RS-232C Asynchronous connection
- a data length of 7 or 8 bits
- a data transmission speed up to 115.2 kbps
a 2-piece terminal 9-pin connector
a USB type-A connector
a USB mini-B connector

The unit supports several different fonts including English, Japanese, Cyrillic, Thai, and Chinese. Some fonts may need to be downloaded. Fonts can be expanded in width and height up to eight times. The touch panel is analog resistive film. This unit uses natural air circulation as a cooling method. Without a fan, it is imperative the unit is installed according to manufacturer directions. Please read through and understand all installation guidelines as written in associated manuals and user guides before unboxing your new HMI.

Reviews For GP4105W1D

Internal Review

(5.0)

While the GP4100 is a reliable device, it is not designed for use as a warming device for critical alarms or as part of a system that alerts you to machine damage, operator injury, or that can halt your overall system. Such critical alarms must have stand-alone hardware that this unit is not designed to have. New or used GP4105W1D's are available to both purchase and repair. - AX Control Lead Technician

Repair Services For GP4105W1D

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$578

Our highly skilled technicians can repair your GP4105W1D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
