GP-4201T

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
The GP-4201T is a Pro-face GP4000 Series 3.5 inch 320 x 240 QVGA HMI with a TFT Color LCD. The input voltage used for this touchscreen display is 24VDC. It features Qty 2 communication ports and Qty 2 USB ports. The GP4201T includes an onboard lithium battery that allows the HMI to hold the program even when no input voltage is present.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP-4201T to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP-4201T

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product
The GP-4201T is a Pro-face GP4000 Series 3.5 inch 320 x 240 QVGA HMI with a TFT Color LCD. The input voltage used for this touchscreen display is 24VDC. It features Qty 2 communication ports and Qty 2 USB ports. The GP4201T includes an onboard lithium battery that allows the HMI to hold the program even when no input voltage is present.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GP-4201T to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GP-4201T Technical Specifications

Battery Lithium Battery
Display Color 65,536 Colors
Display Type TFT Type Color LCD
Features 10/100 Base-T Ethernet
Global Code PFXGP4201TAD
Input Voltage 24VDC
Manufacturer Pro-Face
Part Number GP-4201T
Resolution 320 x 240 Dots (QVGA)
Screen Size 3.5-Inch
Software Version GP-Pro EX
Touch Panel Resolution 1024 x 1024
Weight 3lbs 2oz

Product Description

The GP-4201T 3.5-inch HMI (human-machine interface) from Pro-face is a small touch screen operator interface that offers optimized viewing angles to allow the user the ability to see the screen from a wider viewing angle.   The backlight touch screen is designed with an analog resistive film that offers 1024 x 1024 resolution.   We also sell this unit under Part number PFXGP4201TAD

The graphic display resolution of the GP-4201T’s touch panel is 320 x 240 pixels (QVGA).  This small unit offers up to over 65K colors (no blink) on its 3.5 inch LCD TFT color display.   The display itself has an area that measures 70.56 mm by 52.92 mm.    The unit carries environmental ratings like IP65f and NEMA Type 4x/13.  It is CE marked, CSA certified, and UL listed.

The GP-4201T has internal programming memory of 8 MB using a Flash EPROM.  The unit has backup memory of 128kb SRAM.  This requires battery backup.   The panel has eight levels of brightness and contrast control.   Please note this unit does not include an SD card.  Communication can be set up through a Type-A USB or a Mini-B USB port or the unit’s Serial RS232-C/422/485 Com port or its isolated RS485 serial port.

The GP-4201T is rated for an input voltage of 24VDC. Power consumption on this model is 10.5 W or less.

AX Control maintains a healthy stock of on-hand, ready-to-ship Pro-face HMIs so we can better meet your need for these components.  For up-to-date information on our inventory stock please reach out to our team, who can let you know a specific timeline for delivery to your location.


Reviews For GP-4201T
Internal Review

The GP4000 Series offers powerful TFT LCD touch panels such as the GP4201T with realistic 3D graphics. With the increase in application memory over previous HMI series, more screens and image files can be created and used. Enhanced durability for use in harsh environments--AX Control Tech Team
