GLC2400-TC41-24V

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The Pro-Face Xycom GLC2400-TC41-24V is a touch panel HMI that features a 7.4 inch color display that displays up to 256 colors and uses 24 VDC input.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GLC2400-TC41-24V to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GLC2400-TC41-24V

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The Pro-Face Xycom GLC2400-TC41-24V is a touch panel HMI that features a 7.4 inch color display that displays up to 256 colors and uses 24 VDC input.

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a GLC2400-TC41-24V to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GLC2400-TC41-24V Technical Specifications

Display Colors 256 colors (without blink)/ 64 colors (with blink)
LCD Type TFT 256 Color LCD
Manufacturer Pro-Face
Model Number 2980025
Resolution 640 x 480
Screen Size 7.4 inch
Series GLC 2000 Series

Product Description

Pro-Face is the manufacture of the GLC2400-TC41-24V. This is an integrated HMI/PLC in one box. It reduces overall system costs by streamlining machine designs like display and control and capitalizing on integrating information in a single unit. The GLC2400-TC41-24V offers precise machine control and monitoring by using powerful logic control algorithms including bit manipulation, timers, mathematical, counters, and logical operations. The GLC2400-TC41-24V is a 7.4-inch touch screen with TFT 256 Color LCD (256 colors, No blink/64 colors, 3-speed blink, the coloring switching is done via software). The screen offers 640 x 480 resolution. The GLC2400-TC41-24V has both RS-232(COM 1) and RS-422(COM 2) Com Ports. It offers a 10 base T Ethernet port, CompactFlash Port, 2CH Flex Network Master Interface, Sound Output, and optional Communication Module Interface. The GLC2400-TC41-24V offers an advanced featured Graphics editor, recipes trending, alarm and event management, security, data logging. The data can be shared in three ways via the internet, CompactFlash, or via ethernet. The GLC2400-TC41-24V has a 32 KB SRAM memory with a 128 KB Flash EPROM. The sound output is an external speaker connection. The sound line output is 2.7Vp-p (rated load: 10kOhm). The speaker output is 70mW (rated load: 8 Ohm, frequency 1kHz). The GLC2400-TC41-24V has the following certifications EN55011, EN61000-6-2, UL/cUL 1604, Class 1, Div 2. It is rated to consume 28W of power or less. The GLC2400-TC41-24V has a single slot for a CF card (CompactFlash).
Reviews For GLC2400-TC41-24V
Internal Review

Having the GLC2400-TC41-24V as an integrated HMI/PLC in one box is a dream to use. Having twice as much resolution as the previous models will be a big upgrade for your company. - AX Tech Team

Repair Services For GLC2400-TC41-24V

Type Lead Time Price Action
Repair Service 1-2 weeks $445

Our highly skilled technicians can repair your GLC2400-TC41-24V. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
Learn More
