The PFXGE4401WAD (GC-4401W) is a 7-inch WVGA HMI with a color TFT display from Pro-face's GC4000 series.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a PFXGE4401WAD to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: PFXGE4401WAD
  • SKU: PFXGE4401WADPX
  • Manufacturer: Pro-face Xycom
  • Series: GC4000 Series

PFXGE4401WAD Technical Specifications

Series GC4000
Part Number GC-4401W
Global Code PFXGE4401WAD
Dimensions 207.8 mm (8.18 in) x 153.2 mm (6.03 in) x 59.8 mm (2.36 in)
Display Size 7.0-Inch
Display Type TFT Color LCD
Resolution 800 x 480 pixels (WVGA)
Backlight LED
Enclosure Rating Front IP65, Rear IP20, NEMA 4 with screw fasteners
Input Voltage DC 24 V
Power Consumption 8.2 W
Operating Temperature 0 to 50 °C (32 to 122 °F)

Product Description

Main Features

The PFXGE4401WAD is a widescreen HMI from the Pro-face GC4000 series. It may also be found under the name "GC-4401W." This model is unique in its 7" WVGA TFT color display. The application memory of this model is 8 MB of flash EPROM, while the backup memory is 128 KB. This unit runs on 24 V of DC power.

Display Information

The display of the PFXGE4401WAD is remarkable in its 800 by 480 pixels WVGA resolution, LED backlight, and ability to display up to 65,536 colors. This resolution makes the display clearly readable and viewable from wider angles. The LED backlight is not only good for illuminating the viewing area at 8 variable brightness levels, but it is also energy efficient and reliable. The backlight is estimated to last around 20,000 hours or more when continuously run at 25°C until the brightness level decreases to 50% of the original value or the screen begins to flicker. The TFT-type LCD is not only a better quality image over other types of LCDs like STNs, but it also helps allow this model to display the large number of colors that it can. This adds yet another layer of customization and convenience to this model.

Power Information

As mentioned previously, this unit is designed to run on DC24V power, with an acceptable range limit of 20.4 to 28.8 V. Thanks to features such as the energy-efficient LED backlight, the unit as a whole only takes up 8.7 W of power. The unit has an in-rush current rating of less than or equal to 50 A.

Reviews For PFXGE4401WAD

Internal Review
(5.0)

The PFXGE4401WAD is a good choice of HMI for operators who will frequently be needing to view their display from shallower angles and not always straight ahead. The combination of a widescreen resolution with a bright and clear TFT display makes this one of the best displays for viewing from side angles. The energy saved from the LED backlight also makes this a more long-term cost-effective HMI over older models with fluorescent bulbs. -AX Control Lead Technician
