The Pro-face APL3600T Series APL3600-TD-CD2G TFT Color LCD 12.1-inch Touch-Panel that displays 262,144 Colors at 800 x 600 pixels (SVGA)



Sell Surplus: Have a APL3600-TD-CD2G to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: APL3600-TD-CD2G
  • Manufacturer: Pro-face Xycom
  • Series: APL3000 Series

APL3600-TD-CD2G Technical Specifications

Display Type TFT Type Color LCD
Global Code PFXPL36xxTDxxxxx
Input Voltage DC24V
Keypad/Display Resistive Film (Analog)
Model Number APL3600-TD
Resolution 800 x 600 pixels (SVGA)
Screen Size 12.1 inch

Product Description

The APL3600-TD-CD2G is a 12.1 inch Touch-Panel PC manufactured by Pro-face Xycom. The APL3600-TD-CD2G is a panel computer that works off DC24V power. It comes standard with an Intel 2.0 GHz DuoCore CPU with Windows XP Pro OS. Standard memory is 1GB, expandable to 4GB (DIMM socket x 2.) The APL3600-TD-CD2G has 64MB video memory and a graphics display resolution of 800 x 600 pixels (SVGA.) It has 262,144 colors on its TFT LCD display. The touchscreen is a resistive film, 1024 x 1024.

The APL3600-TD-CD2G has 4 rear USB ports and 1 front USB port. It features 4 serial ports that are RS-232C D-sub 9 pin. COM 1 is RI/+5V switchable and RS-422/RS-485 switchable. COM 2 is RI/+5V switchable. The unit also has two 8-pin LAN ports on the rear of the unit; both can auto-change to 10Base-t/100Basetx. Lan 1 is also able to auto change to 1000Base-T. There is a rear RAS Remote Health Monitor 9-pin socket connector.

The APL3600-TD-CD2G has a 250GB hard drive, SATA interface, IDE interface, 8GB CF card and a DVD-RW drive.

The APL3600-TD-CD26 is cooled by forced air and a CPU fan. For easier operation and maintenance, and for improved ventilation, it is recommended the user install the PL at least 50 mm (1.97 inches) away from structures or other equipment. Be sure surrounding air temperature and humidity are within the specified working ranges of 32 to 122 degrees Fahrenheit without HDD or 41 to 122 degrees Fahrenheit with HDD, and a relative humidity of 10 to 90% non-condensing.

Reviews For APL3600-TD-CD2G

Internal Review

This ruggedized touch panel PC from Proface Xycome offers a SATA interface, an IDE interface, a 250 GB hard drive, as well as 8 GB of storage via the unit's CF card. Read the associated Proface manuals for additional details--AX Control Tech Team
