Pro-face APL3000-BD-CM18 from the APL3000B Series of Industrial Node PC Supports Windows XP with a 250GB Hard Drive Powered by a 24VDC Power Supply.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a APL3000-BD-CM18 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

APL3000-BD-CM18

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (6)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.50 (6)
  • Click a star to rate this product
Pro-face APL3000-BD-CM18 from the APL3000B Series of Industrial Node PC Supports Windows XP with a 250GB Hard Drive Powered by a 24VDC Power Supply.

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More

Sell Surplus: Have a APL3000-BD-CM18 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

APL3000-BD-CM18 Technical Specifications

Global Code PFXPL30xxBDxxxxx
Input Voltage DC24V
Keypad/Display Node PC (No Display)
Model Number APL3000-BD

Product Description

The APL3000-BD-CM18 is an Industrial Node PC from Pro-face. The APL3000-BD-CM18 is designed to run on a DC24V power supply. It operates on a Celeron M440 1.86 GHz CPU and comes standard with Windows XP Pro/XP ML. The APL3000-BD-CM18 has a solid state drive for reliability and faster data access and is RoHS directive-conforming.

Some of the specifications of the APL3000-BD-CM18 include:

  • Graphics display resolution of 640 x 480 pixels (VGA) and 1600 x 1200 pixels (UXGA)

  • RAS 9-pin connectors

  • 60 GB hard disk drive.

  • 2 expansion slots

  • Size is 12.1 x 15 x 19

  • four serial ports (RS-232C)

  • 2 LAN ports. LAN1: auto change to 10BASET/100BASETX. LAN2: auto change to 10BASET/100BASETX

  • Sound available. Speaker out--3.5 mm mini-pin jack connector

  • DVD-RW drive

The APL3000 has optional accessory items available, including USB cables(1 meter and 5 meters,) CF cards (128MB, 256MB, 512MB, 1G,) DIMM memory modules, and hard drive units.

As noted before, the APL-3000 is designed to run on DC24V. Power consumption on 2-slot is 120W or less, on 4-slot is 145W or less. Allowable voltage drop for the APL3000-BD-CM18 is 5ms or less. Voltage endurance is AC1000V 20mA for one minute between charging and FG terminals. Insulation resistance is DC500V 10MΩ (minute) between charging and FG terminals.

Operating temperature is 32 to 122 degrees Fahrenheit without HDD, 41 to 122 degrees Fahrenheit with HDD, 10 to 90% relative humidity, non-condensing. Electrostatic discharge immunity of 6kV. UL listed. CE marked. CSA approved.

  • APL3000-BD-CM18-2P-1G-EM2G
  • APL3000-BD-CM18-2P-1G-EM2G-D
  • APL3000-BD-CM18-2P-1G-M
  • APL3000-BD-CM18-2P-1G-NO16S
  • APL3000-BD-CM18-2P-1G-SU
  • APL3000-BD-CM18-2P-1G-XM16S
  • APL3000-BD-CM18-2P-1G-XM250
  • APL3000-BD-CM18-2P-5M-2J250D
  • APL3000-BD-CM18-2P-5M-EM2G
  • APL3000-BD-CM18-2P-5M-EM2G-D
  • APL3000-BD-CM18-2P-5M-NO16S
  • APL3000-BD-CM18-2P-5M-XM16S
  • APL3000-BD-CM18-2P-5M-XM250
  • APL3000-BD-CM18-4P-1G-EM2G
  • APL3000-BD-CM18-4P-1G-EM2G-D
  • APL3000-BD-CM18-4P-1G-M
  • APL3000-BD-CM18-4P-1G-NO16S
  • APL3000-BD-CM18-4P-1G-SU
  • APL3000-BD-CM18-4P-1G-XJ250
  • APL3000-BD-CM18-4P-1G-XM16S
  • APL3000-BD-CM18-4P-1G-XM250
  • APL3000-BD-CM18-4P-5M-EM2G
  • APL3000-BD-CM18-4P-5M-EM2G-D
  • APL3000-BD-CM18-4P-5M-NO16S
  • APL3000-BD-CM18-4P-5M-XM16S
  • APL3000-BD-CM18-4P-5M-XM250
Reviews For APL3000-BD-CM18
Internal Review

This Proface Xycom Industrial Node PC uses a 24 VDC input. It offers two PCI slots and 1 GB memory in a ruggedized unit designed to withstand the more challenging conditions of industrial applications. See related Proface manuals for additional information. --AX Control Tech Team

Repair Services For APL3000-BD-CM18

Type Lead Time Price Action
Repair Service 1-2 weeks $641

Our highly skilled technicians can repair your APL3000-BD-CM18. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
