Parker Eurotherm EtherNet LINK Card L5352

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a L5352 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: L5352
  • SKU: L5352PES
  • Manufacturer: Parker Eurotherm SSD
  • Series: Link Hardware

L5352 Technical Specifications

Manufacturer Eurotherm Parker SSD
Series SSD Link / Eurotherm Drives
MPN L5352
Product Type Linkcard
Model Ethernet Linkcard
Manual Number HR470898
Voltage 5 VDC
Dimensions 4.72H x 1.25W x 3.54D inches, 0.35lbs

About the L5352

L5352

The L5352 model from Parker Eurotherm Solid State Drives (a subsidiary from the Parker Hannifin Corporation), is an EtherNet LINK Card, meant to interface with the open protocol network that is able to connect to it by an EtherNet device. This card is able to bridge the gap between a LINK control system and an EtherNet device when the card is plugged into either a LINK Station or a LINK Rack. This model is a part of the LINK 2 group, and in order to be successfully operated, the L5352 absolutely must be controlled by an EtherNet master server, such as something like a scanner in a programmable logic controller (PLC) or a PC with supervisory control and data acquisition (SCADA) software system architecture. The terminal it is outfitted with takes the form of an RJ 45 connector.

The L5352 LINK Card model comes with a pair of LED lights to indicate the statuses of both the device’s general physical status, and the bi-colored (green and red) network communications status.

The physical dimensions of the L5352 give the device a compact frame, with a height of 120 millimeters, a width of 32 mm, and a 90 mm depth. It is a lightweight piece of technology, only 0.35 pounds.

AX Control’s technical staff is available to make any repairs if there are any issues incurred during product shipment. We offer a well-rounded warranty of up to three years.

Contact our team if you have any irreparable inventory of this model if there are any in your possession, we will make sure to dispose of it in an environmentally efficient manner to keep both the environment safe and to keep the market safe from broken merchandise.

Frequently Asked Questions about L5352

What is the function of a Ethernet device?
The L5352 is a Ethernet Linkcard that creates a Ethernet network to communicates and provides a connection with a Ethernet master device.
What is the L5352 controlled by?
When the L5352 is working with both the Ethernet network and the Link network, the L5352 should be controlled by Ethernet master.
What do the two LED lights on the front of the device indicate?
There are two LED lights ocated on the front of the L5352. The top light indicates the network stauts while the bottom indicates the module status. You can find a chart in the manual  HR470898  that lays out the meanings of the flashing LED lights.
  • L5352-Issue 1
  • L5352-Issue 2
  • L5352-Issue 2.1
  • L5352-Issue 3
  • L5352-Rev. 2.0
  • L5352-Rev. 2.1
  • L5352-Rev. 3.0
  • L5352-Rev. 4.1
