Parker Eurotherm DeviceNet LinkCard L5351

AVAILABILITY:

IN STOCK
SHIPS IN 1-2 DAYS

Sell Surplus: Have a L5351 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: L5351
  • SKU: L5351PES
  • Manufacturer: Parker Eurotherm SSD
  • Series: Link Hardware

L5351 Technical Specifications

Manufacturer Euroterm Parker SSD
Series SSD Link / Eurotherm Drives
MPN L5351
Product Type DeviceNet Communication Card
Model Linkcard
Manual Number HA353798
Voltage 5 VDC
Dimensions 4.72H x 1.25W x 3.45D

About the L5351

L5351

This model, designated with the manufacturing part number (MPN) of L5351, the DeviceNet LinkCard, was initially developed by the Parker Eurotherm SSD company, a subsidiary of the Parker Hannifin Corporation.

The L5351 DeviceNet LinkCard is on an open protocol network that is able to provide an easy method of network connectivity with the right components to connect to. The L5351 DeviceNet model is a member of the LINK 2 family of products and is able to bridge a gateway between a LINK control system and DeviceNet software, when it is installed onto a LinkStation model or a LinkRack model.

The L5351 LinkCard model only operates as a Group 2 server unit, and is able to be controlled by a DeviceNet master controller, such as a scanner that is set in a programmable logic controller. The terminals are included in the form of a pluggable screw connector.

This device comes outfitted with a pair of indicator LED lights: a module status LED, which indicates if the L5351 is powered on or off, if it is in standby mode, if there is a minor, recoverable issue, or even a severe, irreparable issue, or if the module is in self-test mode. The network connectivity status is a bi-colored LED, and indicates if the device is offline, online, but not connected, if it is successfully connected, if there are any I/O connections that are in a timed out state, if there is a failure in a communication device, and if the device is in a Communication Faulted state.

Frequently Asked Questions about L5351

What is the purpose of the L5351?
The L5351 is a Linkcard that plugs into a Linkrack and create a network between the Link control system and DeviceNet. The L5351 allows informantion to be shared between the two networks.
What does it mean if the LED light is red?
The LED lights indicate the status of the L5351. When the LED light is flashing red, that means a recoverable fault has been detected, but if the LED light is red, a unrecoverable falut has been found and needs replacing.
Where should the L5351 be mounted?
The L5351 is held in a Touchsafe IP20 enclouse that is designed to be installed inside a Eurotherm L5300 Series. The L5351 should be kept in a environment with little condensation/humidity and a temperature between 140158 degrees fahrenheit.
How can a user troubleshoot the L5351 DeviceNet Communications Card?
The L5351 DeviceNet Card by Parker Eurotherm Drives has two distinct LEDs that allow the technician to diagnose various failures, intermittant connections, etc. The upper LED is the network status LED while the lower is the module status LED. Various combinations of Green, Red, and/or Off as the LED state along with the status indicate a reason for the issue. The LED status can mean anything from a communication error to an offline status in Network LED status or a faulty card or device in self-test mode in Module LED status
What instruction manual or datasheet relates to the L5351 DeviceNet card by Parker SSD Drives?
The L5351 DeviceNet Communications Interface Technical Manual HG353798 Issue 3 provides a detailed introduction, installation instructions, troubleshooting proceedure, and other necessary information for the knowledgable use of the L5351 DeviceNet Communication Card. Multiple revisions of this module are available as hardware and various manuals are available as well.
Is Packard Bell onetwo L5351 related to the Parker L5351 DeviceNet Card?
No, this is a completely unrelated part and has no similarity to the communication card supported by Parker SSD Drives.
  • L5351-Issue 1
  • L5351-Issue 2
  • L5351-Issue 2.1
  • L5351-Issue 3
  • L5351-Rev. 2.0
  • L5351-Rev. 2.1
  • L5351-Rev. 3.0
  • L5351-Rev. 4.1
