Parker Eurotherm FireWire LinkCard L5312

AVAILABILITY:

IN STOCK
SHIPS TODAY

Sell Surplus: Have a L5312 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: L5312
  • SKU: L5312PES
  • Manufacturer: Parker Eurotherm SSD
  • Series: Link Hardware

L5312 Technical Specifications

Manufacturer Eurotherm Parker SSD
Series SSD Link / Eurotherm Drives
MPN L5312
Product Type Linkcard
Model Firewire Linkcard
Manual Number HA468120
Voltage 5 VDC
Dimensions 4.72H x 1.24W x 3.54D inches, 0.3lbs

About the L5312

L5312

Designed and produced by the Parker Eurotherm Corporation, the Firewire LinkCard (designated with the manufacturing part number of L5312) is an interface module that bridges the connection between a Link component and the Firewire network. When the L5312 LinkCard is plugged into a LinkRack or integrated into a LinkStation card entry port, it is then able to successfully communicate with any other modules that are also connected to the Firewire network by a standard IEEE 1394 Firewire cables. The L5312 comes outfitted with three integrated cable ports, which can be used in any sort of combination.

The L5312 module was developed with two LED lights integrated into the hardware to indicate the module’s operational status and the network communication connectivity. The operation LED comes in one single color, green, and is lit when the device is powered on and fully operational.

The network connectivity LED is bi-colored with both red and green, and numerous shades of lighting indicate different issues. No light at all means the device is either not turned on or not programmed into the Link configuration. A flashing red indicates either that there is no power on the AC890 Firewire bus, or that the Firewire cable is not connected to the L5312. A steady amber color means that it is waiting for the Link2 host to initialize. A flashing green means bus power is on, but the L5312 does not detect any Link or AC890 nodes, and a steady green means that there are several nodes to connect to.

Frequently Asked Questions about L5312

What is the function of the L5312?
The L5312 is a Linkcard that is plugged into a Linkrack to communicate and send information with other modules within the Link network.
How many ports is the L5312 equipped with?
The L5312 has three ports that are six pin cable interface and can be used with multiple conbinations.
Does AX Control have the manual for the L5312?
AX Control has the manual for the L5312 that describes the basic function, technical specifications, and installation process. You can find the manual at axcontrol.com or by searching the manual number, HA468120 , online.
Can multiple L5312 FireWire modules be installed in the same link rack L5300 or linkstation L5392?
A rack, component, or display in the Parker Eurotherm SSD Link Series can only contain one L5312 as it communicates with other cards using the firewire network communication. An L5311 RTN Linkcard cannot be used alongside the L5312 in an application.
What are the firewire linkcard's LED Status indicators used for?
The network status LED and module status LED on the front of the L5312 use colored lights (green, red, off) either lit, off, or flashing to quickly inform the user of the troubleshooting proceedure needed to remedy the fault, communication loss, or hardware issue related with the L5312
  • L5312-Issue 1
  • L5312-Issue 2
  • L5312-Issue 2.1
  • L5312-Issue 3
  • L5312-Rev. 2.0
  • L5312-Rev. 2.1
  • L5312-Rev. 3.0
  • L5312-Rev. 4.1
