890SD-532240C0-B00-1A000

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The 890SD-532240C0-B00-1A000 Standalone Drive by Parker

AVAILABILITY:

IN STOCK
SHIPS IN 1-2 WEEKS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 890SD-532240C0-B00-1A000 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 890SD-532240C0-B00-1A000
SKU: PES-59107

Manufacturer: Parker Eurotherm SSD
Series: AC890 Variable Frequency Drives

Description
Revisions
Repairs
Warranty
Manuals

890SD-532240C0-B00-1A000 Technical Specifications

Part Number	890SD-532240C0-B00-1A000
Manufacturer	Parker
Series	AC890 Variable Frequency Drives
Humidity Rating	Maximum 85% non-condensing
Protection Rating	IP20
Altitude	Up to 1000m ASL
Operating Temperature	0 to 45 degrees Celsius
Manual Number	HA471133
Power (HP)	15 HP

About the 890SD-532240C0-B00-1A000

The 890SD-532240C0-B00-1A000 is a 15 HP Standalone Drive. This unit is from the AC890 Variable Frequency Drives series by Parker. This series is designed to control speed and position of AC motors and motor applications.

The 890SD-532240C0-B00-1A000 has a few atmospheric specifications that need to be followed. The unit does not have protection against any of these elements and exposure to these could cause damage or malfunction of the unit. The unit should not be exposed to:

Flammables
Corrosives
Dust
Liquids

The drive can be used with a range of AC motors, which allows for more flexibility. These motors are:

AC Induction Motors
Torque Motors
PMAC Brushless Motors

Frequently Asked Questions about 890SD-532240C0-B00-1A000

Does the 890SD-532240C0-B00-1A000 allow for sensorless vector control?

Yes, this unit has sensorless vector control. There are also three other operating modes, which are open-loop control, closed-loop control and PMAC servo control.

What applications can the 890SD-532240C0-B00-1A000 be used for?

The 890SD-532240C0-B00-1A000 can be used for printing, rotary shear, and cut-to-length, as well as other industrial applications.

Reviews For 890SD-532240C0-B00-1A000

Internal Review

(5.0)

The 890SD-532240C0-B00-1A000 is able to integrate into existing systems quite easily, which allows for users to keep their systems the same, even when using a new AC890 unit. The 890SD-532240C0-B00-1A000 is compatible with a range of communications systems, which also helps to connect the unit to existing systems. Make sure both units are on the same network to ensure connection. - AX Control Lead Technician

Repair Services For 890SD-532240C0-B00-1A000

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$4178

Our highly skilled technicians can repair your 890SD-532240C0-B00-1A000. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty
