Home Parker Eurotherm SSD AC890 Variable Frequency Drives 890SD-2-0024C-B-00-A-US

About | Product Specifications | FAQs

890SD-2-0024C-B-00-A-US

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The 890SD/2/0024C/B/00/A/US Standalone Drive from Parker

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 890SD-2-0024C-B-00-A-US to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 890SD-2-0024C-B-00-A-US
SKU: PES-59032

Manufacturer: Parker Eurotherm SSD
Series: AC890 Variable Frequency Drives

Description
Repairs
Warranty
Manuals

890SD-2-0024C-B-00-A-US Technical Specifications

Part Number	890SD/2/0024C/B/00/A/US
Series	AC890 Variable Frequency Drives
Manufacturer	Parker
Frame C Weight	16.8 lbs
HP Rating	7.5 HP
Operating Temperature	0 to 45 degrees Celsius
USB Type	USB programming port
Humidity Rating	Maximum 85% non-condensing
Protection Rating	IP20

About the 890SD-2-0024C-B-00-A-US

The 890SD/2/0024C/B/00/A/US is a Standalone, 7.5 HP drive from Parker's AC890 series. The 890SD/2/0024C/B/00/A/US has three-phase AC supply inputs. The AC890 series was designed to control speed and position of AC motors and motor applications. The 890SD/2/0024C/B/00/A/US can serve a wide range of motors.

The 890SD/2/0024C/B/00/A/US has a number of important features that are central to the SD units. Some of these features include:

Torque and speed signal outputs
Brake switch with an option to add external braking resistor
Operator keypad and display

Another key feature of the 890SD/2/0024C/B/00/A/US is the STO function. This stands for Safe Torque Off, which helps to eliminate any unwanted motor start-ups. There are two STO channels that work together so that if one faults, the other remains functioning.

Frequently Asked Questions about 890SD-2-0024C-B-00-A-US

What is the Switching Frequency of the 890SD/2/0024C/B/00/A/US?

The 890SD/2/0024C/B/00/A/US has a 3 kHz switching frequency. In servo mode, the frequency is 4 kHz or 8 kHz.

Where can the 890SD/2/0024C/B/00/A/US be mounted?

The 890SD/2/0024C/B/00/A/US can be mounted in a cubicle. The 890SD/2/0024C/B/00/A/US should not be wall-mounted.

Reviews For 890SD-2-0024C-B-00-A-US

Internal Review

(5.0)

The 890SD/2/0024C/B/00/A/US is a standalone drive, allowing this unit to be used by itself for motor control. This is useful because it reduces the need for multiple units, which can cause cluttering. The 890SD/2/0024C/B/00/A/US is also one of the more compact units from the AC890 series, allowing users to take up less space with their unit. - AX Control Lead Technician

Repair Services For 890SD-2-0024C-B-00-A-US

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$3450

Our highly skilled technicians can repair your 890SD-2-0024C-B-00-A-US. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year

Learn More
