Home Parker Eurotherm SSD AC890 Variable Frequency Drives 890CD-53230SC0-000-1A000

890CD-53230SC0-000-1A000
2 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

890CD-53230SC0-000-1A000

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 890CD-53230SC0-000-1A000 Drive by Parker

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 890CD-53230SC0-000-1A000 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 890CD-53230SC0-000-1A000
  • SKU: PES-59086
  • Manufacturer: Parker Eurotherm SSD
  • Series: AC890 Variable Frequency Drives

890CD-53230SC0-000-1A000 Technical Specifications

Part Number 890CD-53230SC0-000-1A000
Manufacturer Parker
Series AC890 Variable Frequency Drives
Operating Temperature 0 to 45 degrees Celsius
Altitude Up to 1000m ASL
Humidity Rating Maximum 85% non-condensing
Protection Rating IP20
Axis Synchronization Internally via FireWire IEEE1394
Constant Torque Rating 150% overload for 60 seconds

About the 890CD-53230SC0-000-1A000

The 890CD-53230SC0-000-1A000 is a 20 HP drive from Parker. The unit was manufactured for the AC890 series of Variable Frequency Drives. There are several important manuals to go along with the AC890 series. These can be found under our "Manuals" tab on this product page.

There is a general manual and a frame manual, both of which have important information on the series. The general manual includes details like:

  • benefits of the series
  • technical and electrical details
  • features of the series

The frame manual is more specific in the information it gives. Some of the information in the frame manual includes:

  • programming
  • trips and faults
  • installation

The frame manual also includes a part number breakdown, which is helpful to identify key information on the unit based on the part number.

Frequently Asked Questions about 890CD-53230SC0-000-1A000

What is STO?

STO stands for Safe Torque Off, which is designed to prevent unwanted or unexpected motor starts. This feature is offered with the 890CD-53230SC0-000-1A000.

What are some of the benefits of the AC890 series?

Some benefits of this series include being used in demanding industrial applications, having multiple feedback options, and replacing older, analog solutions.

Reviews For 890CD-53230SC0-000-1A000

Internal Review
(5.0)

The 890CD-53230SC0-000-1A000 offers 30% more peak, which is special to the design of this unit. This unit can also be connected to a Common Bus Supply which creates a Common Bus System. The 890CD-53230SC0-000-1A000 is able to connect to a variety of communications systems, which are listed in the general manual. - AX Control Lead Technician

Repair Services For 890CD-53230SC0-000-1A000

Type Lead Time Price Action
Repair Service 1-2 weeks $3455

Our highly skilled technicians can repair your 890CD-53230SC0-000-1A000. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
