Home Parker Eurotherm SSD AC890 Variable Frequency Drives 890CD-5-0030C-N-00-A-US

About | Product Specifications | FAQs

890CD-5-0030C-N-00-A-US

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The 890CD/5/0030C/N/00/A/US Common Bus Drive by Parker

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 890CD-5-0030C-N-00-A-US to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 890CD-5-0030C-N-00-A-US
SKU: PES-59015

Manufacturer: Parker Eurotherm SSD
Series: AC890 Variable Frequency Drives

Description
Repairs
Warranty
Manuals

890CD-5-0030C-N-00-A-US Technical Specifications

Part Number	890CD/5/0030C/N/00/A/US
Manufacturer	Parker
Series	AC890 Variable Frequency Drives
Braking Option?	No Braking Option
Frame C Dimensions (in)	17.0 H x 4.57 W x 10.16 D
Protection Rating	IP20
Operating Temperature	0 to 45 degrees Celsius
HD Amps	27
DC Fusing	Internal

About the 890CD-5-0030C-N-00-A-US

The 890CD/5/0030C/N/00/A/US is a Common Bus Drive with a horsepower rating of 20 HP. The 890CD/5/0030C/N/00/A/US was manufactured by Parker, with a place in the AC890 Variable Frequency Drives series.

There are a variety of online materials from Parker that are designed to help with the AC890 series. These materials can be found under the "Manuals" tab on this product page. The manuals can help with:

Trip/fault codes
Technical specifications
Installation
Maintenance

The 890CD/5/0030C/N/00/A/US has a size C frame, which weighs 14.6lbs. The 890CD/5/0030C/N/00/A/US has multiple communication options, including:

Modbus/TCP
RS485
ControlNet
DeviceNet

There are other communication standards that the 890CD/5/0030C/N/00/A/US can connect to. For a full list, refer to page 8 in the 890CD/5/0030C/N/00/A/US Manual.

Frequently Asked Questions about 890CD-5-0030C-N-00-A-US

What does STO stand for?

STO stands for Safe Torque Off, which is a safety feature that the 890CD/5/0030C/N/00/A/US has. This feature works to prevent surprise start ups on AC motors. There are two STO channels in the AC890 units.

What is the humidity rating of the 890CD/5/0030C/N/00/A/US?

The 890CD/5/0030C/N/00/A/US should be in a maximum 85% non-condensing humidity level.

Reviews For 890CD-5-0030C-N-00-A-US

Internal Review

(5.0)

The 890CD/5/0030C/N/00/A/US has a variety of benefits, including multiple feedback choices. These choices are: incremental encoder, resolver, and EnDat 2.1 encoder. Another benefit of the 890CD/5/0030C/N/00/A/US is its ability to take on high performing applications. This includes cut-to-length and position synchronization. - AX Control Lead Technician

Repair Services For 890CD-5-0030C-N-00-A-US

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	$3568

Our highly skilled technicians can repair your 890CD-5-0030C-N-00-A-US. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year

Learn More
