890CD-231550B0-000-1A000

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The 890CD-231550B0-000-1A000 drive by Parker

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

2 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a 890CD-231550B0-000-1A000 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: 890CD-231550B0-000-1A000
SKU: PES-59064

Manufacturer: Parker Eurotherm SSD
Series: AC890 Variable Frequency Drives

Description
Repairs
Warranty
Manuals

890CD-231550B0-000-1A000 Technical Specifications

Part Number	890CD-231550B0-000-1A000
Manufacturer	Parker
Series	AC890 Variable Frequency Drives
Operating Temperature	0 to 45 degrees Celsius
Frame B Weight	11.0 lbs
Frame B Dimensions (in)	17.0 H x 2.85 W x 10.16 D
Protection Rating	IP20
Digital Inputs	7; Configurable 24 VDC
Altitude	Up to 1000m ASL

About the 890CD-231550B0-000-1A000

The 890CD-231550B0-000-1A000 is a 1.5 horsepower Common Bus Drive from Parker. This unit was designed for the AC890 Variable Frequency Drives series. The drives in the AC890 series are designed to control speed and position of AC motors and motor applications.

Parker has provided original manual materials for the AC890 series, which are helpful for processes like installation and maintenance. There is a general manual and a frame manual for the AC890 series. The frame manual has an important chapter on trips and faults that could occur in the AC890 units. Some of these trips include:

Undervoltage
Brake resistor
Current limit
Power loss stop

Some of these trips are accompanied by descriptions and potential reasons for the trip in the manual. All of these trips and more can be found in Chapter 11 of the Frames B-D manual.

Frequently Asked Questions about 890CD-231550B0-000-1A000

What feedback options does the 890CD-231550B0-000-1A000 have?

The 890CD-231550B0-000-1A000 is compatible with all feedback options, which are an incremental encoder, an EnDat 2.1 (SinCos) encoder, and a resolver.

What kind of environment should the 890CD-231550B0-000-1A000 be kept in?

The 890CD-231550B0-000-1A000 should be away from corrosives and flammables. This unit is also sensitive to dust.

Reviews For 890CD-231550B0-000-1A000

Internal Review

(5.0)

The 890CD-231550B0-000-1A000 is a 1.5 horsepower drive with a variety of functions. This unit can be used with AC motors and motor applications. The unit is also compatible with the Common Bus Supply units. These can connect to create a Common Bus System. - AX Control Lead Technician
