Product Description
The GP377-SUB is a graphic control panel that was made to be a part of the GP-377 series. The GP377-SUB is an obsolete product, but AX Control may have it in stock in either refurbished condition or in brand new condition from available surplus stock. Do not hesitate to contact one of AX Control’s sales representatives to find out more about this product and whether or not AX Control has it in stock.
The GP-377 series of control panels is a significant upgrade of Digital’s GP370 series of panels, with improvements to functionality and overall performance. In addition, rather than using the optional 2-port adapter like its predecessor, the GP377 uses the Mitsubishi Electric Corporation’s GPP software package. To adapt to this, the graphics panel’s rear face tool connector now has the ability to provide 2-port feature communication.
Prior to the installation of a GP-377, be sure that the installation gasket is properly placed inside the unit, which is located on the back side of the unit. The GP-377 series’ manual strongly recommends that you use the installation gasket so that it can absorb vibration and repel water. To properly check the GP-377 if the installation gasket is attached, place the unit on a surface that is level with the display facing downward. Ensure that the installation gasket is firmly placed into the installation gasket’s groove, which runs along the frame’s perimeter.
Installation of the GP-377 series of displays is simple. Simply place the display into the panel. Then, you must insert each of the four fasteners into its applicable insertion slot. Check to make sure that the fastener is flush with the rear of the attachment hole. Finally, you must use a screwdriver in order to tighten the screws into place and properly secure the unit.
