KV-10T2W

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.57 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.57 (7)
  • Click a star to rate this product
Keyence PLC Module

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a KV-10T2W to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: KV-10T2W
  • SKU: KV10T2WKE
  • Manufacturer: Keyence
  • Series: KV Series PLC

About the KV-10T2W

The KV-10T2W is logic controller that is part of the KV Series by Keyence. The KV-10T2W is a small grey component with a 24VDC, 0V, C, 500, 501,502, and 503 ports along the bottom. Along the top, there is a C, 000, and 001 port.

The Keyence KV-10T2W has LED lights for easy display. The unit has a small pull-down cover on the front to place an Ethernet cable to connect with your system, as well as in and out ports along the outer right side. Along the bottom of the KV-10T2W there are vents to allow airflow to cool the unit.

This is considered one of the world's smallest PLCs. It has six inputs and four outputs. It allows for easy usage via Windows ladder software.

The KV-10T2W has a variety of expansion options, as well as a 20kHz clock pulse output. There is a temporary data memory of thirty-two words, and full data memory (16 bites) or 1,000 words.

The average number of steps to program this PLC is 500. It is compatible with the expanded ladder and ladder diagram. Programs will be retained for a minimum of ten years with the EEPROM, and are able to be rewritten a minimum of 50,000 times. The KV-10T2W also has an internal and special utility relay of one hundred and sixty (160). Along with a high-speed counter with two auto-reset up counters with a max input frequency of 10kHz.

This particular series isn't compatible with GP2300 /GP2301 / GLC2300 series. You will need to use a Digital CA1-EXCBL/D25-01 extension cable when connecting to additional units.

Frequently Asked Questions about KV-10T2W

Is there a back up for data if there is an interruption in the power of my Keyence KV series?
Yes, there is a back up function for when there is an interruption in the power of your unit. There is a RAM that is backed up and it has an electrical double layer capacitor that is built in to the basic units by Keyence. The contents of the internal utilities in the relay and data memories and the counters with there current value are saved in the RAM when there is an interruption in the power of the unit. It also depends on the temperature of the unit, if the backed up time is saved correctly. The data can become corrupt or accidently deleted if the power is "OFF" more than the time held by the RAM. To not have the data deleted or made corrupt, have the data be saved on the "EEPROM" by using the back up function.
What exactly does the eeprom save in the data for the Keyence unit?
For the Keyence KV series, the "EEPROM" saves programs, counters, and memories. If the power gets turned off or just interrupted the data is saved on the EEPROM. The contents can be read automatically once the power is turned back on to the unit. The built in electrical double layer capacitor will save changed data when data is changed but not saved before turning the unit OFF,  it can not be found on the EEPROM. Only with a built in electrical double layer capacitor the data can be saved for 2 months with the unit turned OFF at 25 degrees Celcius (77 degrees Fahrenheit), but 20 days or more can cause the data to be corrupt or deleted all together. If the unit is going to be turned OFF for a while, then the data should be save on the EEPROM.

Repair Services For KV-10T2W

Type Lead Time Price Action
Repair Service 1-2 weeks $843

Our highly skilled technicians can repair your KV-10T2W. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.
All PLCs, HMIs, and Turbine Control Boards: 3 Years
All AC/DC and Servo Drives: 2 Years
All Motors: 1 Year
