HE-QX65IAF-16

Q: How many user keys does the HE-QX65IAF-16 Touchscreen offer?

This HE-QX65IAF-16 unit&#39;s pushbuttons can be referred to as user keys; it offers seven configurable keys and one SYSTEM key for a total of eight.

5.00 (2)
Click a star to rate this product

5.00 (2)
Click a star to rate this product

The HE-QX65IAF-16 12" OCS Color Touchsceen made for Horner Electric's QX Color-Touch OCS Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a HE-QX65IAF-16 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: HE-QX65IAF-16
SKU: HE-59421

Manufacturer: Horner Electric
Series: QX Color-Touch OCS

Description
Repairs
Warranty
Manuals

HE-QX65IAF-16 Technical Specifications

Part Number	HE-QX65IAF-16
Functional Description	12" OCS Color Touchsceen
Series	QX Color-Touch OCS
Manufacturer	Horner Electric
Voltage	24 VDC
Steady State Current	1.25 A @ 24 VDC
Inrush Current	30 A @ 24 VDC for 1 ms
Height	10.25”
Width	12.87”
Depth	2.52”
Control Memory	256K Ladder with 32KB Register Space
Control Scan Rate	0.2mS / K Ladder Logic
Faceplate Material	Lexan HP92 GE Plastic
Network	On-Board Ethernet 100BaseT
Alternate Part Number	HEQX651C000

About the HE-QX65IAF-16

The HE-QX65IAF-16 12" OCS Color Touchscreen made for Horner Electric's QX Color-Touch OCS Series comes with a set of important hardware component inclusions seen in most QX models. Some of these are its:

8 pushbuttons
3+ Ethernet ports
Vented chassis
POWER LED

The POWER LED featuring on the front faceplate of this E-QX65IAF-16 12" OCS Color Touchscreen is not the only LED on its assembly, it is however the only LED that exists outside of the E-QX65IAF-16 unit's attached back pack module.

E-QX65IAF-16 12" Display Details

As the E-QX65IAF-16 12" OCS Color Touchscreen is essentially halfway made up of a display screen, it is important to consider a number of ratings for this component specifically. The E-QX65IAF-16 12" OCS Color Touchscreen's display screen has:

a 800 x 600 TFT display type
a true size of 12.1 inches
9.7“W x 7.3“H display screen dimensions
8 MBytes of display memory

Frequently Asked Questions about HE-QX65IAF-16

How many user keys does the HE-QX65IAF-16 Touchscreen offer?

This HE-QX65IAF-16 unit's pushbuttons can be referred to as user keys; it offers seven configurable keys and one SYSTEM key for a total of eight.

How many screens could this HE-QX65IAF-16 support?

This HE-QX65IAF-16 Touchscreen Module can support up to 1,023 screens at a time.

Reviews For HE-QX65IAF-16

Internal Review

(5.0)

This HE-QX65IAF-16 color-touch offering can display over thirty thousand colors, on a screen that is the second-largest out of its greater QX Series. The CAN, FIBER OK and OK LEDs are the LEDs that feature on its back pack module. The HE-QX65IAF-16 also has a typical control scan rate despite its larger assembly. - AX Control Lead Technician
