Home Horner Electric QX Color-Touch OCS HE-QX651AK-16

❮

❯

About | Product Specifications | FAQs

HE-QX651AK-16

Q: Does the HE-QX651AK-16 display module have a metal or plastic faceplate?

This HE-QX651AK-16&#39;s faceplate is made up of GE Plastic&#39;s durable Lexan HP92 plastic material.

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The HE-QX651AK-16 12" Active Industrial Touchscreen made for Horner Electric's QX Color-Touch OCS Series

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a HE-QX651AK-16 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: HE-QX651AK-16
SKU: HE-59423

Manufacturer: Horner Electric
Series: QX Color-Touch OCS

Description
Repairs
Warranty
Manuals

HE-QX651AK-16 Technical Specifications

Part Number	HE-QX651AK-16
Functional Description	12" Active Industrial Touchscreen
Series	QX Color-Touch OCS
Manufacturer	Horner Electric
Display Type	800 x 600 TFT
Display Size	12.1”
Screen Dimensions	9.7“W x 7.3“H
Display Memory	8 MBytes
Screens Supported	1,023 screens
Network	Ethernet 100BaseT
External Discrete I/Os	SmartStack, SmartStix
Fiber Optic Extension	FOX104 / 404
Back Pack Temperature Rating	32 - 122°F
Back Pack Humidity Rating	5 to 95% Non-condensing
Alternate Part Number	HEQX651C000

About the HE-QX651AK-16

The HE-QX651AK-16 12" Active Industrial Touchscreen featured here is one of the larger LCD-based displays manufactured for the Color-Touch OCS Series, which means that its series of configurable pushbuttons has been included below its display. Some other critical hardware components for this unit are its

LCD liquid crystal display
Numerous Ethernet ports
Circuitry venting
Plastic chassis (vented)
POWER front LED

The POWER LED in this HE-QX651AK-16 12" Active Industrial Touchscreen's assembly is rather self-explanatory as it glows green to indicate that the unit is receiving proper input voltage.

HE-QX651AK-16 Touchscreen Dimensions and Ratings

As the second-largest model of QX Touchscreen, the HE-QX651AK-16 12" Active Industrial Touchscreen here comes with its own critical dimensions and voltage ratings, including its:

24 VDC voltage (+/-10%)
1.25 A steady state current (at 24 VDC)
30 A inrush current (24 VDC 1 ms)
10.25” height
12.87” width
2.52” mounting depth

Frequently Asked Questions about HE-QX651AK-16

Does the HE-QX651AK-16 display module have a metal or plastic faceplate?

This HE-QX651AK-16's faceplate is made up of GE Plastic's durable Lexan HP92 plastic material.

How do SmartStack modules relate to this HE-QX651AK-16 unit?

This HE-QX651AK-16 unit can accept several plastic SmartStack modules for external I/O options.

Reviews For HE-QX651AK-16

Internal Review

(5.0)

Each one of the Ethernet ports in this HE-QX651AK-16 device's assembly can function either as an RS-232 or as an RS-485 for serial communications. In terms of memory, a CompactFlash or CF slot is provided. Seven of the HE-QX651AK-16 Touchscreen's eight total pushbuttons are configurable, outside of the necessary SYSTEM button. - AX Control Lead Technician
