UR-TLA

4.80 (5)
Click a star to rate this product

4.80 (5)
Click a star to rate this product

The UR-TLA Low-Voltage Universal Relay Module made for GE Vernova's UR Universal Relays Series

AVAILABILITY:

IN STOCK
SHIPS IN 1-2 WEEKS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a UR-TLA to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: UR-TLA
SKU: GM-59505

Manufacturer: GE Multilin
Series: UR Series Universal Relays

Description
Repairs
Warranty
Manuals

UR-TLA Technical Specifications

Part Number	UR-TLA
Functional Description	Low-Voltage Universal Relay Module
Series	UR Series Universal Relays
Manufacturer	GE Vernova
Fault Locator Method	Single-ended
Fault Locator Relay Accuracy	±1.5% (V > 10 V, I > 0.1 pu)
CT Rated Primary Input	1 to 50000 A
CT Rated Secondary Input	1 A or 5 A by connection
Nominal DC Voltage	24 to 48 V at 3 A
Min/Max DC Voltage	20 / 60 V
Altitude	Up to 2000 m

About the UR-TLA

A number of specific applications and functioning systems are considered compatible with this low voltage UR-TLA unit. These include in:

Protection, Control, and Monitoring
Utility Substations
Industrial Systems
Generation Systems
Transmission Systems

The UR-TLA can also provide basic maintenance through trending and data analysis.

UR-TLA Hardware

The UR-TLA Low-Voltage Universal Relay Module made for GE Vernova's UR Universal Relays Series features a number of important different user-programmable hardware and software elements. Some of these are its:

Control Pushbuttons
Flexcurves and Flexlogic
Flexelements and Flexstates
LED Tests
Non-Volatile Latches
Selector Switches
User-Programmed LEDs

Three total interruptible LED tests exist for this module; these tests can be initiated from any digital input or userprogrammable condition. Sixteen total individually-programmed latches are available in this device's assembly; Set-dominant or Resetdominant latches only.

UR-TLA Selector Switches

The selector switches in the assembly of this UR-TLA Universal Relay Module have their own set of critical specifications indicated in chart form here:

Switch Count	2 Switches
Upper Postion Limit	1 to 7 in steps of 1
Selecting Mode	Time-out or Acknowledge
Time-Out Timer	3.0 to 60.0 s in steps of 0.1
Control Inputs	Step-up and 3-bit
Power-Up Mode	Restore from Non-volatile Memory or Synchronize to a 3-bit Control Input

Frequently Asked Questions about UR-TLA

How is the UR-TLA Module mounted?

This UR-TLA unit is mounted horizontally, per the "A" letter rounding out its functional part number.

How many user-definable displays are available for this module?

16 total user-definable displays are available for the UR-TLA Universal Relay Module, with invoking and scrolling available from any keypad or any userprogrammable condition,
including pushbuttons.

Reviews For UR-TLA

Internal Review

(5.0)

The monitoring reporting rate for this Universal Relay is customizable, and can be selected anywhere from 1, 2, 5, 10, 12, 15, 20, 25, 30, 50, 60 or 120 times per second. 1 to 16 channels are available for this unit's data channel logging. The UR-TLA Module also has a crucial event logger with an overall capacity of 1024 events. - AX Control Lead Technician

Repair Services For UR-TLA

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	Ask	Get Quote

Our highly skilled technicians can repair your UR-TLA. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year

Learn More
