General Electric Multilin's UR-RLH is a low power power supply module intended for installation in the Universal Relays series.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a UR-RLH to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: UR-RLH
  • SKU: URRLHGM
  • Manufacturer: GE Multilin
  • Series: UR Series Universal Relays

UR-RLH Technical Specifications

Manufacturer General Electric Multilin (GE)
Weight approx. 2lb, 2oz
Dimensions approx. 6.5” L, 6.5” W, 1.75” H
Software EnerVista

Product Description

A low power version of the module series, General Electric Multilin’s UR-RLH is a power supply module intended for installation in the Universal Relays series. The module functions at a range of 24 to 48 V nominal (DC only). The power supply module offers power input to the relay and its dry contact input connections, making it an essential component for proper relay function. The UR-RLH also contains the battery for the Universal Relay, so this module will need to be removed and later replaced when the battery needs to be changed out for whatever reason.

The UR-RLH power supply module includes a critical failure relay element, a form-C device that becomes energized once the system boots successfully, no self-test failures occur, and control power is properly applied. In the event that on-going self-testing detects a critical failure during normal operation (or if control power is lost), the critical failure relay is de-energized.

Other modules in the Universal Relays series include the CPU module, CT/VT module, digital input and output module, transducer input and output module, and inter-relay communications.

Frequently Asked Questions about UR-RLH

What type of power supply is a General Electric UR-RLH UR series Multilin power supply?
A UR-RLH is a Multilin power supply module of the second generation (UR-RH). The first generation power supply modules replaced by the UR-RH generation are designated as UR-1H. In 2014, a third generation of power supply modules was introduced as the UR-SH modules. The UR-SH power supply modules were designed to be a complete replacement for the other generations and are compatible with the same universal relays of the UR Multilin series.
What type of voltage range does the UR-RLH power supply module have?
The UR-RLH has a low “LO” voltage range as indicated by the ‘L’ in the part number. In contrast, a high power supply module has a voltage range from 125-250 V AC/CD for the first and second generations. For the third generation (UR-SH) this voltage range has increased to 125 to 300 V AC/DC.
What is the isolation voltage level for the UR-RLH GE Multilin power supply module for universal relays of the UR Multilin series?
The isolation voltage level is 2000 V AC for the second generation. The output power for this generation is 35 W. With the new UR-SH power supply modules, this isolation voltage level increased to 2300 W and the output power increased to 45 W.

Reviews For UR-RLH

Internal Review
(5.0)

The Universal Relays series is able to continually self-test system hardware and functions, displaying faults through the LED indicators located on the faceplate if the UR-RLH malfunctions. -AX Control Tech Team
