Produced by General Electric Multilin, the UR-9TH is intended to operate within the Universal Relays series as a CPU module.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a UR-9TH to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: UR-9TH
  • SKU: UR9THGM
  • Manufacturer: GE Multilin
  • Series: UR Series Universal Relays

UR-9TH Technical Specifications

Manufacturer General Electric Multilin
Manufacturing Location Ontario, Canada
Weight approx. 1lb, 10oz
Software EnerVista UR

Product Description

Intended to operate within the Universal Relays series as a CPU module, the UR-9TH is produced by General Electric Multilin. This version of the CPU module supports multiple ports in relation to its Parallel Redundancy Protocol (PRP) element. This feature enables seamless recovery in the event of a network failure by employing a combination of frame duplication and LAN duplication techniques.

Multilin’s UR-9TH and the Universal Relays series as a whole cuts down on troubleshooting time by providing users with errors detected by its self-assessment capabilities. For example, the WRONG TRANSCEIVER error code indicates when the variety of SFP does not match the CPU type; users can then use data collected by the relay and compare it against their CPU module to know the exact nature of the issue. Similarly, the Equipment Mismatch Self-Test can assess whether the installed hardware modules properly match the order code stored in the CPU, encouraging users to ensure modules are properly installed and paired.

The CPU module can handle multiple types of input and output signals and can help manage communications with a programming device, operator interface, or other UR units. CPU modules including the IEEE 1588 protocol can also synchronize these messages with accuracy up to one microsecond.

Frequently Asked Questions about UR-9TH

What types of CPU options are found in the UR (universal relay) series of GE Multilin universal relays?
The exact CPU module will be labeled with a part number such as UR-9TH, which specifies what characteristics the CPU module has. In some cases, such as for the UR F35 Multiple Feeder Protection System, the exact order option of the CPU is important with respect to matching it to the CT/VT module option. If the version (new or old) of the CPU does not match the version (new or old) of the CT/VT module then the F35 will display either a hardware mismatch or a display error indication on screen to alert to the user that the components are not in agreement.  Each UR (universal relay) contains a variety of components such as the CT/VT module, the I/O module, the CPU, a power supply, inter-relay communications, and more. The number 9 differentiates the CPU modules from the other components. These part numbers will appear of the form RH-9 with a letter following the number 9 that indicates the specific characteristics of that CPU.  For example, a 9P CPU will have the characteristics of the RS485 and the single mode ST 100Base-FX.

Reviews For UR-9TH

Internal Review
(5.0)

The UR-9TH is one of the newest and most advanced units in the series of CPU modules, offering Ethernet capabilities with Parallel Redundancy Protocol, making it an excellent choice for protecting and controlling any power system. -AX Control Tech Team

Repair Services For UR-9TH

Type Lead Time Price Action
Repair Service 1-2 weeks $1958

Our highly skilled technicians can repair your UR-9TH. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
