Produced by GE Multilin, the C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX Universal Relay is a Substation Hardened Programmable Logic Controller.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX
  • SKU: C30M03HCHF6DH67MXXPXXUXXWXXGM
  • Manufacturer: GE Multilin
  • Series: UR Series Universal Relays

C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX Technical Specifications

# of Data Logging Channels 16
# of FlexCurves 4
Maximum Oscillography Records 64
Operating Temperature –40 to 60°C
Overvoltage Category II
RTD Input Wire Types (3-wire) 100 Ω Platinum, 100 and 120 Ω Nickel, 10 Ω Copper
Storage Temperature –40 to 85°C

Product Description

Featuring 8-Form A outputs, General Electric Multilin’s C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX is a microprocessor-based power substation control and monitoring system. The Controller System is capable of recording data on the connected system and safeguarding it when hazardous conditions such as overcurrent or overfrequency arise during normal operation. The C30 combines a number of protective and metering features in one compact unit, reducing the need for extraneous equipment and reducing costs and number of connections. The relay runs on a number of highly-specifiable setpoints that control when trips and alarms are triggered (in addition to many other facets of the device’s functionality).

The C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX includes Multilin’s FlexLogic technology, an impactful UR-platform programming logic engine that can form customized control schemes and protection, further reducing the need for auxiliary equipment and connections. Enacted every 2ms irregardless of logic complexity, FlexLogic can execute up to 1024 lines of logic to assist the power system. The relay also employs Multilin’s FlexCurves which provide customized overload curves that provide highly-configurable protection to the substation system.

Equipped with a variety of metering and monitoring functions, General Electric Multilin’s C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX can measure the status of connected external devices and report on the data collected, including time-stamps for convenient reference. These functions include disturbance and fault recording, device health diagnoistics, and event recording. These features generally reduce troubleshooting time, as they provide detailed reports of system conditions at the time that faults/events transpire. The relay can also capture cybersecurity related events such as invalid password attempts, logins and logouts, and remote access, allowing your company better monitoring of user activity.

Frequently Asked Questions about C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX

What are the unique product characteristics and specifications when ordering for the C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX Hardened Programmable Logic Controller within the Universal Relay Multilin system?
The C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX is a Multilin C30 universal relay hardened programmable logic controller within the universal relay Multilin system. This logic controller is designed to provide the user with substation control logic that can replace SOE recorders and increase the capacity of I/O protection devices. The C30 is able to accept feedback from other control or protection devices in the system using communications that are much more cost effective than hard-wired signals. This form of communication (high-speed peer-to-peer) reduces the bay and station wiring required as well. The order specifications unique to the C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX Hardened Programmable Logic Controller are as follows. The 03 (-M03-) alphanumeric code indicates the IEC 61850 software option. The 'HCH' designation shows that this C30 is the standard horizontal 19 inch rack controller with a high voltage power supply. The F6D shows that this unit has 16 digital inputs for its digital I/O specification and 8 Form-A (no monitoring) outputs (H67 alphanumeric). The XX indication following the last order specifications show that no module is selected in these respects.  As one can see, the variability is profound with regard to the C30, adding to user tailored customizability of the controller.


Reviews For C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX

Internal Review
(5.0)

The C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX works in tandem with Multilin’s industry-leading EnerVista program, providing a streamlined and convenient interface for all your power substation control needs. It can trend & export data, display system values, efficiently configure setpoints, and more. -AX Control Tech Team

Repair Services For C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX

Type Lead Time Price Action
Repair Service 1-2 weeks $1802

Our highly skilled technicians can repair your C30-M03-HCH-F6D-H67-MXX-PXX-UXX-WXX. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
