Part of General Electric Multilin's FM series, the FM2-712-C is a feeder system management unit that provides protective and control elements to the feeder system.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a FM2-712-C to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: FM2-712-C
  • SKU: FM2712CGM
  • Manufacturer: GE Multilin
  • Series: FM2 Feeder Manager

FM2-712-C Technical Specifications

Manufacturer General Electric Multilin (GE)
Manufacturing Location Markham, Ontario, Canada
Dimensions approx. 7.4” L, 4.4” H, 5” W
Weight 3 lb
Shipping Dimensions 8.3" x 5.625" x 5.8" (211 mm x 143 mm x 147 mm)
Shipping Weight max. 4 lbs (1.8 kg)
Pollution Degree II
Overvoltage Category II
Insulation Voltage 300 V
Operating Temperature Range 0° C to 60° C
AC Nominal 120 VAC, range 80 – 135 VAC

Product Description

This unit of the Feeder Manager 2 line of hardware is designated under the ID classification of “FM2-712-C.” The Feeder Manager 2 modules are a part of the General Electric series known as the Multilin series.

The FM2 modules are all outfitted with a large array of similar details, protective measures, and specifications. The features included are items like a three phase thermal overload protection unit,  (rated at 49/51), and earth fault protective measures, rated at 50 Gs. An undervoltage reclose system is installed as well, to be utilized if the intake received is less than the nominal amount needed (which is up to 120 volts of alternating current, or 50 hertz of energy).

The FM2-712-C unit is a black box variation of the Feeder Manager design, similar to the FM2-722-C model. This means that this unit is designed without a display monitor, with a keypad and status LED indicator lights. Multilin's EnerVista FM2 software program can be used to edit setpoints, check parameters, and perform other tasks that could normally be performed using the integrated liquid-crystal display.

If you’re looking for a unit that is integrated with a 2 line, 80 character display monitor, then we also have the FM2-712-PD and the FM2-722-PD.

These Feeder Manager models are all available from AX Control, after being completely repaired and fully refurbished. Each product purchased from us here is covered by the well-detailed, extensive warranty that we provide. We also have an exchange credit program in place; this means that we’ll lower your price quoting in exchange for industrial equipment that is irreparable and nonfunctional, and we will dispose of it in an environmentally friendly manner.

Frequently Asked Questions about FM2-712-C

How does the FM2-712-C work with the EnerVista software program? What kind of features does the software program provide?

EnerVista FM2 provides GE Multilin’s FM2-712-C with a streamlined user interface and a suite of tools for convenient unit management and data exporting. Users can configure inputs and outputs, view the event recording log, edit system settings, and view relay parameters. EnerVista can also detect the model number of the FM2 device in order to produce options and data relevant to the specific version of the series (in this case the FM2-712-C), removing the need for manual configuration of the device. EnerVista FM2 also provides help features within the program and is capable of automatically updating manuals, FAQs, and drivers to keep the user as up to date as possible. One benefit of the EnerVista software is that Multilin has intentionally designed it so that it has extremely low hardware requirements, reducing the need for expensive hardware to support the program. Users will find that equipping their relay with EnerVista FM2 is easy and cheap.

Reviews For FM2-712-C

Internal Review
(5.0)

General Electric Multilin’s FM2-712-C is capable of protecting the power system by trigger trips when the unit detects hazards such as ground faults or thermal overload; this feature prolongs feeder distribution system life and makes it a superb choice for the user’s safeguarding needs. - AX Control Tech

Repair Services For FM2-712-C

Type Lead Time Price Action
Repair Service 1-2 weeks $969

Our highly skilled technicians can repair your FM2-712-C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
