750-P1-G1-S1-HI-A20-R

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (1)
  • Click a star to rate this product
The 750-P1-G1-S1-HI-A20-R includes a metering function that can determine values such as voltage, frequency, watthour cost, percent of load-to-trip, and running and maximum demand. The relay can use its metering function to trigger an alarm when the breaker maintenance threshold is exceeded.
Request a Quote Request Repair
Request a Quote Request Repair

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 750-P1-G1-S1-HI-A20-R to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 750-P1-G1-S1-HI-A20-R
  • SKU: GM-18779
  • Manufacturer: GE Multilin
  • Series: 750/760 Feeder Management Relay

750-P1-G1-S1-HI-A20-R Technical Specifications

Manufacturer General Electric Multilin
Series 750/760 Feeder Management Relay
Part Number 750-P1-G1-S1-HI-A20-R
Analog Input Conversion Range 0 to 21 mA
Communications RS232, RS422, RS485 ports
Features Simulation Function, Drawout Construction
Manual 1601-0120-AE
Pollution Degree II
Relay Dimensions 7” W, 6.5” L, 8.5” H
Weight 17.42 lb

About the 750-P1-G1-S1-HI-A20-R

  • The 750-P1-G1-S1-HI-A20-R is designed to streamline distribution feeder system management and extend system life.
  • Equipped with numerous protection features, it aims to reduce strain on system components and lower troubleshooting times through its metering and data logging capabilities.
Front Panel Features
  • The front panel is segmented into four main sections:
    • 40-character Liquid Crystal Display (LCD): Alphanumeric, indicates various user-configurable system values when not actively in use.
    • Keypad: Allows for manual setpoint configuration and general navigation of the relay.
    • LEDs: Indicate system problems and active processes (total of 20 LEDs).
    • RS232 Port: Enables direct connection to a computer running the EnerVista 750 software.
Metering and Data Logging Capabilities
  • Includes a metering function that can determine values such as:
    • Voltage
    • Frequency
    • Watthour cost
    • Percent of load-to-trip
    • Running demand
    • Maximum demand
  • The metering function can trigger an alarm (indicated by the 20 LEDs) when the breaker maintenance threshold is exceeded.
Security and Configuration
  • Passcode protection can be implemented to prevent unauthorized adjustments of setpoints.
  • This password protection applies to both manual editing from the front panel and editing via the EnerVista 750 program.
  • For manual setpoint configuration, a jumper must be installed on the rear terminal.
