The 745-W3-P5-G5-LO-A GE Multilin 745 Transformer Protection System

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 745-W3-P5-G5-LO-A to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 745-W3-P5-G5-LO-A
  • SKU: GM-59205
  • Manufacturer: GE Multilin
  • Series: 745 Transformer Protection System

745-W3-P5-G5-LO-A Technical Specifications

Part Number 745-W3-P5-G5-LO-A
Manufacturer General Electric Multilin
Series 745 Transformer Protection System
Windings per Phase 3 Windings Per Phase
Control Power (VDC) 20 to 60 VDC
Options Analog Inputs/Outputs
Control Power Type Low Control Power
Logic Inputs 16 Inputs

About the 745-W3-P5-G5-LO-A

The 745-W3-P5-G5-LO-A is a 745 Transformer Protection System from General Electric Multilin. The 745-W3-P5-G5-LO-A is designed to provide protection for small, medium, and large power transformers, autotransformers, and reactors.

This relay has a plethora of features that are important for the overall function of the part. There are multiple communications options, including RS232 and RS485/RS422 serial ports. The 745-W3-P5-G5-LO-A also has a number of protective features. Some of these are:

  • Overcurrent protection
  • Under/overfrequency protection
  • Overexcitation protection

Another useful feature for the 745-W3-P5-G5-LO-A is the simulation/testing feature. This allows users to test the functionality of the 745-W3-P5-G5-LO-A before use with a transformer. The simulation uses preexisting recorded data or computer generated data to run its tests. The simulation will alert users to any potential trips or alarms on the 745-W3-P5-G5-LO-A.

Frequently Asked Questions about 745-W3-P5-G5-LO-A

What are the setpoints for on the 745-W3-P5-G5-LO-A?

The setpoint groups can be used to address the protection requirements of different power system configurations.

Will faults and trips show up on the display of the 745-W3-P5-G5-LO-A?

Yes, the display allows for any diagnostic messages to be seen from trips and alarm conditions.

Reviews For 745-W3-P5-G5-LO-A

Internal Review
(5.0)

The 745-W3-P5-G5-LO-A has a variety of different protective features to keep transformers running smoothly. This relay is a low control power unit, with slightly less power needed than the higher control power units. This unit also has analog inputs and outputs that are not on every relay. - AX Control Lead Technician

Repair Services For 745-W3-P5-G5-LO-A

Type Lead Time Price Action
Repair Service 1-2 weeks $2880

Our highly skilled technicians can repair your 745-W3-P5-G5-LO-A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
