The 369-HI-R-M-0-0-H-0 of General Electric Multilin's 369 series is a high-control power unit, accepting inputs in a range of 110 to 250 V direct current and 100 to 240 V alternating current at 50/60 Hz frequency.

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a 369-Hi-R-M-0-0-H-0 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 369-Hi-R-M-0-0-H-0
  • SKU: 369HiRM00H0GM
  • Manufacturer: GE Multilin
  • Series: 369 Motor Management Relay

369-Hi-R-M-0-0-H-0 Technical Specifications

Dimensions approx. 29.6cm H x 10.7cm W x 20.5cm L
Ground Current Input Frequency 20 to 100 Hz
Insulation Class I
Phase Current Input Conversion True RMS, 1.04 ms/sample
Software EnerVista 369
Waveform Capture Length 3 buffers containing 16 cycles of all current and voltage channels
Weight approx. 10 lbs

About the 369-Hi-R-M-0-0-H-0

Intended to protect and control medium-sized motors and accompanying parts, General Electric Multilin’s 369-HI-R-M-0-0-H-0 is a Motor Management Relay and part of the 369 series.

The relay includes ten LED indicators on the front of the panel that accompany the 40-character liquid-crystal display and keypad. The LED indicators include service, trip, alarm, aux 1, aux 2, BSD, RRTD, metering, COM1, and COM2 statuses to provide a quick reference for users. The LEDs offer insight into system health and the various processes that are occurring within the relay and motor system.

The 369-HI-R-M-0-0-H-0 of General Electric Multilin’s 369 series is a high-control power unit, accepting inputs in a range of 110 to 250 V direct current and 100 to 240 V alternating current at 50/60 Hz frequency. This contrasts with the low-power version of the series, which accepts a control power range of 20 to 60 V direct current and 20 to 48 V alternating current. Prospective buyers should purchase the unit appropriate for their control power needs, as exceeding the range is likely to result in system damage.

The 369-HI-R-M-0-0-H-0 also comes with the optional conformal coating, providing additional protection against corrosion, humidity, temperature, and dust. Conformal coating is a thin, breathable polymeric layer that can be applied through a variety of means. If a prospective buyer is interested in a model with additional features that appears to be lacking a conformal coating, AX Control is capable of adding this feature to any model that doesn’t already have it: simply inquire within.

Frequently Asked Questions about 369-Hi-R-M-0-0-H-0

What is the hard environment option for the GE Multilin 369-Hi-R-M-0-0-H-0 three phase motor management and protection digital relay?
As an additional feature that characterizes some 369 Multilin relays, the harsh environment option may be incorporated with relays similar to the GE Multilin 369-Hi-R-M-0-0-H-0 three phase motor management and protection digital relay. As indicated by the second to last alphanumeric position, the 369-Hi-R-M-0-0-H-0 includes the H option (or the harsh environment option). This option provides the relay with additional protection, in the case of operation in a harsh or chemical environment.
What are the control power specifications of the 369-Hi-R-M-0-0-H-0 three phase motor management relay?
The 369-Hi-R-M-0-0-H-0 GE motor management Multilin relay has a high control power range. The VDC range for this unit is from 50 to 300. The VAC range control power is from 60 to 265.
Can you tell me about the security access capabilities of the front panel for the 369-Hi-R-M-0-0-H-0 GE motor management relay?
The 369-Hi-R-M-0-0-H-0 GE digital relay has two settings for access security. The unit can either be "Read Only" or "Read and Write". The read only option limits the ability of the user to change actual values. These actual values and set points can only be viewed. If the relay is set to read and write the user is able to modify set points to be stored.

Reviews For 369-Hi-R-M-0-0-H-0

Internal Review
(4.0)

This system needs an external disconnect in order to isolate the main voltage supply; users should ensure they have the proper setup or the system will not function as intended. -AX Control Technicians
