IC220MDL642 Technical Specifications

Input 24VDC POSITIVE LOGIC, 4PT
MPN IC220MDL642
Requires IC220TBK122

Product Description

The VersaPoint station may include IC220MDL642, a Discrete Input Module manufactured by GE Fanuc Automation. This module has 4 logic points, and the lifecycle status is active. The input voltage is 0-30 VDC and the input response time is less than 1 msec. The LED indicator is Bus Diagnostics Status indication of inputs. The nominal current consumption of US is a maximum of 1.0 amperes. The on state current is 4 mA and the off state current is 0.4 mA. The current consumption for Local Bus UL is 40 mA. The connection style is a 2 and 3 wire connection.

The datasheet number for this module is GFK-1902, and the module ID is BE hex (190 decimal). Input/output modules have terminal points to accommodate 2-, 3-, and 4-wire sensors or actuators depending on the module. Connections are made to Terminal Strips, which are ordered separately. The electronics power loss of an I/O module can be calculated following the formula in the module’s datasheet. The power loss of the module must not exceed the power loss of the housing. Additional I/O module grounding beyond the voltage jumper FE is not required. Four digital sensors can be connected to the module. The housing dimensions are 0.480 in x 4.724 in x 2.795 in.

The operating humidity may occasionally reach 85% without incident. The maximum permissible load current per sensor is 250 mA. The maximum permissible load current from the terminal is 1.0A. This module has a class of protection at Class 3 according to VDE 0106 and IEC 60536. Protective devices on the module include protective circuits of the power terminal that protect against surge voltage and polarity reversal. Electrical isolation may be provided. Diagrams of IC220MDL642, as well as example configurations within the VersaPoint system, may be found in the user manual.

  • IC220MDL642-AA
  • IC220MDL642-BA
  • IC220MDL642-CB
  • IC220MDL642A
  • IC220MDL642B

Repair Services For IC220MDL642

Type Lead Time Price Action
Repair Service 1-2 weeks $345

Our highly skilled technicians can repair your IC220MDL642. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
