IC220ALG320 Technical Specifications

MPN IC220ALG320
Requires IC220TBK203

Product Description

GE Fanuc Automation manufactures the VersaPoint system, of which IC220ALG320 is a part. This unit has an analog output 16 bit voltage and one current channel. The output voltage is 0-20 mA, 4-20 mA, and 0-10V. There are 8 output points. The module has a 2 wire, shielded sensor cable connection style. The output load voltage is 2 kohm (minimum) and the output load current is 500 kohm (maximum).

There are LED indicators for Bus Diagnostics and I/O voltage for analog terminals present. The required terminal strip is IC220TBK203, and it contains one strip. There are 10 of these units in each of the 5 remote cabinets in the control cabinet of the VersaPoint configuration. The maximum length of the associated cable is 250 meters. The analog output module datasheet is GFK-1907.

The current consumption of UL is 35 mA and the current consumption of UANA is 25 mA. The housing dimensions are 24.4 mm x 120 mm x 71.5. The connection style is 2-wire technology. The operating humidity must average 75%, not exceeding 85%. The user must have one analog signal output to connect either voltage or current signals. Only one output must be used on the module. The module has a process data update including conversion time of the digital/analog converter <1 ms. The I/O supply voltage UANA is 24 VDC and the total power consumption is typically ~1.425W. There is a voltage mode and a current mode on the module. Pay attention to guidelines illustrated in the manual for safely handling the VersaPoint system. Please refer to the user manual for more information.
