IC609SJR100 Technical Specifications

Input 115 Volts Alternating Current
MPN IC609SJR100
Output 115/230 Volts Alternating Current

Product Description

The IC609SJR100 device is an I/O unit that was created and manufactured by GE Fanuc for the Series One Junior family of products. This product, like all of the others in the Series One Junior line, is no longer being manufactured by GE Fanuc. Despite this, the IC609SJR100 I/O unit can still usually be found within AX Control’s inventory. Be sure to check our website for this product’s availability in our inventory.

The IC609SJR100 I/O unit’s input is rated as being 115 VAC and its output is rated as being 115/230 VAC. On the top and bottom parts of the IC609SJR100 I/O unit have multiple terminals and ports that can be used as the operator’s disposal. The top part is for the input and the bottom part is for the output. In the top left of the IC609SJR100 I/O unit’s faceplate, there is a total of four LED indicator lights. These lights are labeled as follows from top to bottom: “RUN,” “BATT,” “CPU,” and “PWR.” Below those lights, you will find a large male port. On the right side, there is a display screen with several buttons on its right side.

The IC609SJR100 I/O unit uses pico, fast blow type fuses. These fuses are rated as having 2 Amps for the current and are installed into the IC609SJR100 I/O unit using a soldering technique where it is planted directly into the circuit.

The IC609SJR100 I/O unit weighs a total of about 3.60 lbs. or 1.63 kg. This total does not include shipping materials.

Frequently Asked Questions about IC609SJR100

What is the function of the IC609SJR100?
The IC609SJR100 is a basic unit within the One Jr. Series.
Where do you connect the 115 V ac IN on the IC609SJR100?
The 115 V ac IN connects on the second and third notch.
  • IC609SJR100A
  • IC609SJR100B
  • IC609SJR100C
  • IC609SJR100D
  • IC609SJR100E
  • IC609SJR100F

Repair Services For IC609SJR100

Type Lead Time Price Action
Repair Service 1-2 weeks $340

Our highly skilled technicians can repair your IC609SJR100. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

  • 48-72hr Rush Repair
  • Detailed Repair Reports
  • AX Control Certificate of Warranty
