The IC693UEX011 is part of the Series 90 Micro PLC series from General Electric. This unit contains 8 DC Inputs, 6 relay Outputs, and a 100/240VAC Power Supply. The series is compatible with Logic master 90-30/20 Micro programming software.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a IC693UEX011 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

IC693UEX011

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
The IC693UEX011 is part of the Series 90 Micro PLC series from General Electric. This unit contains 8 DC Inputs, 6 relay Outputs, and a 100/240VAC Power Supply. The series is compatible with Logic master 90-30/20 Micro programming software.

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a IC693UEX011 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

IC693UEX011 Technical Specifications

Casing Black Hard Plastic
Compatible With Series 90-70 PLC
Manufacturer General Electric Fanuc
Output 24VDC 120-240VAC 50/60Hz 2A Pilot Duty
Requirement 4MB Disk Space
Source 100-240VAC 50/60Hz 20VA Max

Product Description

The IC693UEX011 is a part of the Series 90 Micro Programmable Logic Controller (PLC) and was manufactured by General Electric (GE) Fanuc. This series was made to be easily installed and configured and offers advanced programming features. Being part of this series also means that it comes with a built-in CPU, Power supply, and Input/Output count applications. This PLC is a 14-point expansion unit featuring eight DC input points and six relay output points, along with a 24 VDC output power supply. The power specifications that are needed to operate the IC693UEX011 are 100-240 VAC. The module’s inrush time is 2 ms for 40 A and features a hold-up of 10 ms at 85 VAC. Keep this in mind when installing the machine.

It is important to note that base unit Micro PLCs must be turned off during connection to an expansion unit, otherwise the base will be damaged. This cable cannot be substituted by another type or brand, as it contains keyed connectors, and must be correctly connected prior to turning on the device to prevent damage to either unit. Feel free to contact AX Control by either phone or email with any and all questions regarding this product along with others in this series.

  • IC693UEX011AP1
  • IC693UEX011BP1
  • IC693UEX011CP1
  • IC693UEX011DP1
  • IC693UEX011EP1
  • IC693UEX011FP1
  • IC693UEX011JP1
  • IC693UEX011LP1
  • IC693UEX011NP1
  • IC693UEX011PP1
  • IC693UEX011RP1
Reviews For IC693UEX011
Internal Review

The IC693UEX011 was made by General Electric Fanuc and is from their Series 90 Micro series. With it comes extensive software application and configuration abilities. Such as its support for the 90-30 Handheld Programmer whose cable provides connections vital for the HHP and PLC to communicate. -AX Control Technician

Repair Services For IC693UEX011

Type Lead Time Price Action
Repair Service 1-2 weeks $375

Our highly skilled technicians can repair your IC693UEX011. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
