GE QuickPanel Touch Screen GQPK3D200L2P

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a GQPK3D200L2P to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GQPK3D200L2P

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE QuickPanel Touch Screen GQPK3D200L2P

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a GQPK3D200L2P to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

GQPK3D200L2P Technical Specifications

Input Voltage 24 VDC
LCD Type Monochrome Display
Manufacturer GE Fanuc Total Control
NEMA Rating Type 4X/12 IP65
Part Number GQPK3D200L2P
Screen Size 5.7"
Series QuickPanel Jr.
Software Version QuickDesigner Version 3.7

Product Description

GQPK3D200L2P

This model of the QuickPanel Junior section of GE’s QuickPanel touch screens is the GQPK3D200L2P. The QuickPanel series was initially developed by the industrial automation branch of GE, but is now regarded as being obsolete. However, after being fully refurbished and optimized, by our talented repair staff at AX Control, this unit is able to function at peak performance in the industrial workplaces of today.

The GQPK3D200L2P is one of the many 6 inch modules, and is outfitted with a 4 in x 5 in touch screen panel. The information graphics are displayed to the operators in a 240 x 320 pixel resolution. The graphics are shown in only a gray and white monochromatic display.

However, users must note that there are conditions that may cause the brightness of the screen to dim. If the unit’s temperature increases beyond its limit of 40 degrees Celsius, or 104 degrees Fahrenheit. The operational temperature range also goes as low as 0 degrees C, or 32 degrees F. While the GQPK3D200L2P unit is in storage, then the temperature range is from negative 20 Celsius to negative 4 Fahrenheit.

Regarding the power intake, this module runs on an operational supply of 20.4 volts of direct current at minimum, and nominally at 24 volts. The maximum amount of voltage this unit can operate at is 27.6 V/DC.

The internal systems of this model have been graded to withstand up to 1500 volts of alternating current before serious damage happens. There is also a power failure immunity capability, able to stay powered on for 20 milliseconds after being disconnected from a power source before automatic shutdown occurs.

Frequently Asked Questions about GQPK3D200L2P

How many alarms are supported for the GE Fanuc Total Control Quickpanel GQPK3D200L2P?
Reverting back to the owners manual, the total number of 768 Alarms are supported which consist of 3,256 individual files that can be tagged on the GE Fanuc Total Control Quickpanel GQPK3D200L2P. AX Control Inc. has the in house man power to transfer your project files and alarms.
Can I format the GE Fanuc Total Control Quickpanel GQPK3D200L2P?
Yes absolutely, GE Fanuc has made it user friendly to initialize the memory on the Quickpanel. Connecting the GE Fanuc Total Control Quickpanel GQPK3D200L2P to the computer along with the Quickdesigner software, you are then able to format your Panel to factory specifications. AX Control Inc. has all the software for completing this task.
Is the GE Fanuc Total Control Quickpanel GQPK3D200L2P still in production?
The GE Fanuc Total Control Quickpanel GQPK3D200L2P is not currently being manufactured. AX Control Inc. is your number one source for all your HMI needs and repairs!
How do I use the menu bar to use the Quick Panels CF Boot?
Inserting the CF Card into the Quick Panel with the CF memory Loader Tool should be saved and select the CF Boot by touching is on the menu screen. After the Quick Panel restarts, the CF Card Memory Loader Tool will start up. These Quick Panels are also equipped with a Compact Flash slot that can be used to set up the Quick Panel. The Compact Flash can also send screen data and saves the back up data, it is necessary for all the data for the Quick Panels operation.
  • GQPK3D200L2P Series A
  • GQPK3D200L2P Series B
  • GQPK3D200L2P-A
  • GQPK3D200L2P-B
  • GQPK3D200L2P-C
  • GQPK3D200L2P-D
  • GQPK3D200L2P-F
  • GQPK3D200L2P-G
  • GQPK3D200L2P-H
