GE QuickPanel Touch Screen CQPJ2D100S2P

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a CQPJ2D100S2P to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

CQPJ2D100S2P

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (3)
  • Click a star to rate this product
GE QuickPanel Touch Screen CQPJ2D100S2P

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a CQPJ2D100S2P to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

CQPJ2D100S2P Technical Specifications

Input Voltage 24 VDC
LCD Type STN Color Display
Manufacturer GE Fanuc Total Control
NEMA Rating Type 4X/12 IP65
Part Number CQPJ2D100S2P
Screen Size 4.7"
Series QuickPanel Jr.
Software Version QuickDesigner Version 3.7

Product Description

CQPJ2D100S2P

This unit is a part of the QuickPanel series of touch screen models, in the QuickPanel Junior category. The CPQJ2D100S2P model is one of their 5 inch models, with a set of specifications that match that of the usual set of the similarly sized models.

The CQPJ2D100S2P model has a viewing panel that is 4 inches (101.6 millimeters) in width, and then 3 inches (76.2 millimeters). The visual display is an STN type setup, which shows the graphics in full color (8 solid colors, 8 flashing colors). The informational graphics are displayed to the users in a crisp 240 by 320 pixel resolution.

Physically, this 5 inch unit is built with the same setup as the other models in the QuickPanel series. There is a width of 6.75 inches (171.5 millimeters), a height of 5 inches (127 millimeters), and a depth of 2.125 inches (54 millimeters). The weight is also a standard 1.5 pounds, or 0.68 kilograms.

This unit has been fully refurbished by the repair staff here at AX Control. However, this unit is regarded as being outdated and obsolete, and don’t match up to the hardware standards of today’s workplace. It is able to operate at peak functionality. Make sure, however, that the wiring is completely grounded before plugging it in and operating. If not grounded, the CQPJ2D100S2P will make a loud noise. This same noise will also occur if there is a power supply that exceeds past the optimal intake range.

Frequently Asked Questions about CQPJ2D100S2P

What are some wiring cautions that should be known?
The FG terminal is the ground terminal that is connected to the GP Chassis and should be connected and make sure that the wire is grounded. The Quick Panel unit will make an excessive noise if it is not properly grounded. The standard for your country that is applicable should be used for grounding the Quick Panel unit. Be sure to use ring terminals that are sleeve type to prevent the ring terminals from shorting out when ever the terminal block attachment screws are loosened. Also make sure that the power cord is not plugged in and that the plastic terminal strip cover is removed. Make sure that the other three middle terminal screws are removed and the position of the ring terminals match the manuals diagrams, check each wire to be sure that the connections are correct.
What are some things I should know before connecting the power supply?
Before connecting the power supply, a voltage tranformer should be connected to the Quick Panel if the supplied voltage exceeds the units voltage range. Connecting a noise reducing transformer if you hear a lot of noise will help make it less noise. Voltage and Noise Reducing transformers should be used for Quick Panel units that exceed 100VA. The input/output and operational unit lines need to be seperated when supplying power to the Quick Panel unit. Twisting each power wires befor attaching the ring terminals increases the noise resistance of the power.
