GE QuickPanel Touch Screen CQPGCTDE0000

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

Warranty: Learn More

Sell Surplus: Have a CQPGCTDE0000 to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

CQPGCTDE0000 Technical Specifications

Input Voltage 24 VDC
LCD Type TFT Color Display
Manufacturer GE Fanuc Total Control
NEMA Rating Type 4X/12 IP65
Part Number CQPGCTDE0000
Screen Size 7.4"
Series QuickPanel
Software Version QuickDesigner Version 3.7

Product Description

CQPGCTDE0000

This model is a part of the human/machine touch screens developed by the industrial automation section of General Electric. The QuickPanel series is regarded as being more outdated and obsolete parts of equipment and industrial hardware. While being out of production, this unit, as well as the other pieces of automation technology in our inventory, have been completely refurbished and restored. AX Control can guarantee that your purchase is completely operational, and won’t reach you dead on arrival.

The CQPGCTDE0000 unit is one of the QuickPanel 7.4 inch models. Display wise, the viewing panel is outfitted with a standard measurement for its size, a width of 8.05 inches, or 6.69 millimeters, and a height of 6.28 inches, or 159.5 millimeters. The approximate weight of these models are at least 7.7 pounds, or 3.5 kilograms.

The CQPGCTDE0000 comes with an Ethernet port, in order to efficiently implement production reports and share data on all levels of management. This model has even more expanded application memory when compared to other models in the series, with 4 megabytes of Flash EPROM memory. This amount of memory allows for more informational graphics to be displayed to the users and operators of this module, heightening the efficiency of the workplace.

For a power source, this model is equipped to run on an intake of at least 20 volts of direct current. 24 V/DC is the nominal intake for this unit, while the maximum amount of voltage this model can handle to run properly is 27 V/DC.

Frequently Asked Questions about CQPGCTDE0000

How big is the screen on a CQPGCTDE0000?
Reverting back to the owners manual for the CQPGCTDE0000, the screen size is a 7.4" 256 Color TFT LCD Display.
How long does the backlights usually last in the CQPGCTDE0000?
According to the owners manual, the CCFL Backlights are able to withstand 50,000 hours at 25°C on a 24hr. operation. An orange light will indicate that the back light is burned out and the touch screen will not work. The 5" and 6" units are rated at 20,000 hours. The QP-Ethernet panels have a back light that can be replaced and you will be warned when the back light needs to be replaced. The back light's current flow is detected to warn you when the back light is about to burn out, obviously this depends on the condition of the back light and its problems. The back light model number for the QP Ethernet Series Model QPG is HMI-CCT-402. Please make sure that the power is unplugged from the model before replacing the back light to prevent electric shock. Also let the back light cool down before touching, it may be hot. The back light can break and cause an injury if not handled carefully, it is a glass tube and is very fragile.
How many brightness adjustments are on the QPGCTDE0000?
The QPG-CTDE-0000 has 4 levels of adjustment available via touch panel. The QPI Series has 64 colors that it supports, with a 2 Mbyte memory for application.
What types of memory is included with the QPGCTDE0000?
There are two types of Memory in the CQPG-CTDE-0000, which include Application and Data Backup. Application Memory holds 4MB FLASH EPROM. The Data Backup is 256KB SRAM (with lithium backup battery).
  • CQPGCTDE0000 Series A
  • CQPGCTDE0000 Series B
  • CQPGCTDE0000-A
  • CQPGCTDE0000-B
  • CQPGCTDE0000-C
  • CQPGCTDE0000-D
  • CQPGCTDE0000-F
  • CQPGCTDE0000-G
  • CQPGCTDE0000-H
