IC620MDR028 Technical Specifications

Manual GFK-0803B
MPN IC620MDR028
Product Type CPU Unit
Voltage 265 VAC

Product Description

The IC620MDR028 is an I/O Unit made by Ge Fanuc. It was also probably sold by Fanuc was a part of their product lines. It is no longer being supported by either company. AX Control typically tries to maintain the IC620MDR028 in stock. Please consult the website for availability and shipping options.

The IC620MDR028 is a 28-point CPU Unit that has DC Inputs and Relay Outputs that were created to be part of the GE Fanuc Micro PLC series. This device is 76 mm thick, 218 mm wide, and 80 mm tall. It has an 85-264 VAC @ 47-60 Hz power supply voltage. It has a 15-watt power consumption rate. It has an unfused 24 VDC, 8.4 mA per unused point power available from a Vpp-style terminal.

This unit has 16 total DC inputs that have logic circuitry that is optoisolated. An outside device has the ability to use a pull-up resistor to turn on the input by pulling the input point-to-ground. These inputs have an input current of 8.4mA. It has an 11 VDC or higher off-level and a 10.8 or lower on-level.  They have a 7mC off-to-on and 11 mS on-to-off non-adjustable response time. They have an impedance of 3K ohms.

The IC620MDR028 has 12 electromechanical relay output contacts. These relay outputs have N.O. contacts and are grouped as 2 isolated, 2 groups of 4 that share 2 commons, and a group of 2 that share a single common. It has a minimum applicable load of 5 VDC 2 1mA. This device has maximum response times of 10mS and a minimum load of 5 VDC @ 1mA.

Frequently Asked Questions about IC620MDR028

Is the IC620MDR028 compatible with both the operator interface unit and the hand-held programmer?
The IC620MDR028 is compatible with the OIU and the HHP. Both devices can be used to monitor the IC620MDR028's production mode and program.
How should the IC620MDR028 be installed?
The IC620MDR028 is designed to be mounted on either a DNI rail or horizontally on a vertical surface. The system should be installed in a cool and dry enviornment to keep it from becoming damaged.
What are the dimensions of the IC620MDR028?
The dimensions of the IC620MDR028 are 8.6W x 3.15H x 3.0D inches.
