IC620EDR128

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.86 (7)
  • Click a star to rate this product
28 I/O Micro Expnasion PLC Module With DC Power Supply

AVAILABILITY:

IN STOCK
SHIPS IN 3-5 DAYS

Sell Surplus: Have a IC620EDR128 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IC620EDR128
  • SKU: IC620EDR128GFP
  • Manufacturer: GE Fanuc PLC
  • Series: IC620 Micro

IC620EDR128 Technical Specifications

MPN IC620EDR128
Product Type Expander Unit
Voltage 24 VDC
Manual GFK-0803B

About the IC620EDR128

The IC620EDR128 module is one of many expander units that the company GE Fanuc created for their series called Micro PLC. This device can usually be found in our stock, so be sure to check on its status on our website or on the phone.

The IC620EDR128 expander unit provides the user with additional inputs and outputs for a total of 28 points altogether. This device has 16 DC inputs and 12 relay outputs. The voltage for the device’s internal power supply 10 to 28 VDC, although the nominal voltage is 12 to 24 VDC. At 24 VDC, the power consumption rating for the IC620EDR128 expander unit is 8.1 W. With the VPP terminal activated, the IC620EDR128 will have 24 VDC and 8.4 mA per unused point of power available for use.

The IC620EDR128 expander unit’s 16 DC inputs are all opto-isolated away from the logic circuitry. The device’s input current is rated at 4.2 mA when the device is running at 12 VDC and 9.5 mA when it is running at 24 VDC. When the IC620EDR128 expander unit is in its ON state, the maximum level is 9.8 VDC, but when it is in its OFF state, the minimum level is 10.0 VDC.

The IC620EDR128 expander unit’s 12 relay outputs are all electromagnetic relay contacts that have a minimum applicable load of 5 VDC when operating at 1 mA. These relay outputs are normally open contacts with a contact resistance of 5 VDC at 1 mA. The response time for both ON to OFF and OFF to ON is a maximum of 10 ms.

Frequently Asked Questions about IC620EDR128

What do the LED lights indicate on the exterior of the IC620EDR128?
The IC620EDR128 is designed with LED light on the front of the device that indicate the input/output points preformance and the power supply level.
What is the purpose of the IC620EDR128?
The IC620EDR128 is an expander unit within the GE Fanuc Micro Series that provides extra input/output points when needed. If all of the I/O points are used on the CPU, a IC620EDR128 can be connected.
Does AX Control sell the IC620EDR128 reconditioned?
AX Control has both reconditioned and new factory package conditions of the IC620EDR128 in stock and ready for purchase.
